ADI PRO RN-7001501 RG6 Quad-Shielded CATV Cable, 60% AL 40% AL Braid, 18/1 CCS, Non-Plenum, 500' (152.4m) Pull Box, White
Brand: ADI PRO
ADI #:RN-7001501
Model #: RN-7001501
Name: ADI PRO RN-7001501 RG6 Quad-Shielded CATV Cable, 60% AL 40% AL Braid, 18/1 CCS, Non-Plenum, 500' (152.4m) Pull Box, White
- 18 AWG copper-clad steel conductor
- 60% plus 40% aluminum braid
- UL listed to meet CL2 guidelinesor CL2 rated
Sale Type: ADI Choice
Product Overview
Our 500 ft Quad-Shielded Coaxial Cable is constructed of 18AWG with a copper clad steel conductor providing a higher level of shielding for signal retention. Great for various applications such as CCTV, Audio/Video and data communications. With the incredible flexibility of the wire, it makes it very easy to install while providing high quality images. Available in white and black color, UL listed and supports CL2 guidelines.
General Information
Name : ADI PRO RN-7001501 RG6 Quad-Shielded CATV Cable, 60% AL 40% AL Braid, 18/1 CCS, Non-Plenum, 500' (152.4m) Pull Box, White , ADI PROCategory : Coaxial Cables
UPC Code : 840049304239
Country of Origin : Vietnam. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : RN-7001501
Brand Name : ADI PRO
Manufacturer : ADI PRO
Manufacturer Part Number : RN-7001501
Product Line : Siamese
Product Model : RN-7001501
Product Name : Siamese Bare Wire Control Cable
Product Type : Control Cable
Technical Information
American Wire Gauge : 18 AWG
Cable Type : Coaxial
Connector on First End : Bare Wire
Connector on Second End : Bare Wire
Device Supported : Audio/Video Device, Security Camera, Security Device
Impedance : 75 Ohms
Jacket Type : CL2, CM
Number of Conductors : 1
Shielding : Yes
Physical Characteristics
Cable Length : 500 ft
Cable Length (mm) : 152400
Color : White
Package Type : Pull Box
Miscellaneous
Country of Origin : Vietnam
Environmental Certification : RoHS
Environmentally Friendly : Yes
Features : Flexible
