Belden 6200UE 877U1000 16/2 Stranded BC Security and Commercial Audio Cable, Plenum-CMP, Flamarrest Jacket with Ripcord, 1000' (304.8m) UnReel, Natural
6200UE 877U1000
|7B-6200UE87U
Shop All Belden
Belden 6200UE 877U1000 16/2 Stranded BC Security and Commercial Audio Cable, Plenum-CMP, Flamarrest Jacket with Ripcord, 1000' (304.8m) UnReel, Natural
6200UE 877U1000 | 7B-6200UE87U
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Security & Commercial Audio Cable, Plenum-CMP, 2-16 AWG stranded bare copper conductors with Flamarrest insulation, Flamarrest jacket with ripcord.
Main Features
- Easy Pulling & Stripping: Belden's quality jacketing saves installation time and money
- Easy Identification: Cable jackets feature footage room and zone markings
- Solid Construction: Features electrolytic tough pitch (ETP) virgin copper
- Suitable Applications: Intercom/PA Systems, Sound/Audio Systems
- 16AWG, 2 Conductors, 19x29 Stranding
- BC - Bare Copper
- PVC - Polyvinyl Chloride Insulation
- PVC - Polyvinyl Chloride Jacket
- Environmental Suitability: Indoor - Plenum, Indoor
- CMP
General Information
Name: Belden 6200UE 877U1000 16/2 Stranded BC Security and Commercial Audio Cable, Plenum-CMP, Flamarrest Jacket with Ripcord, 1000' (304.8m) UnReel, Natural
Category: Belden, Wire & Cable, Speaker Cables, Plenum Audio Cables
UPC Code: 612825340133
Country of Origin: Mexico. Country of origin is subject to change.
Specifications
ADI Part Number 7B-6200UE87U Application/Usage Intercom/PA Systems, Sound/Audio Systems Brand Name Belden Country of Origin MX Manufacturer Belden CDT, Inc Manufacturer Part Number 6200UE877U1000 Packaged Quantity 305 Product Name 6200UE Security & Sound, 2 Conductor 16 AWG, BC, CMP Product Type Audio/Control Cable
American Wire Gauge 16AWG Cable Rating Plenum Cable Style Coaxial Cable Type Bare Wire Conductor Count 2 Conductor Material Bare Copper CPR Euroclass Rating Eca,EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) Device Supported Audio System, Intercom, Security System, Sound System, Speaker Jacket Type FT6, Plenum Duplex Zip Number of Conductors 2 Number of Pairs 1 Shielding No Solid or Stranded Stranded
Certifications & Standards CMP,Article 800,IEC 60332-1-2,CMP,FT6,Yes,CMP,EU Directive 2003/11/EC (BFR),IEC 60332-1-2,CMP,Article 800,IEC 60332-1-2,CMP,FT6 UL Listed Yes
Operating Temperature (T-T) 0-75°C
UPC 612825340133
Cable Length 1000' Color Clear Height 1000.0' Insulation Material PVC (Polyvinyl Chloride) Jacket Material PVC (Polyvinyl Chloride),LS PVC (Low Smoke PVC) Material Bare Copper, PVC
Voltage Rating 300V
Length 1000'
Limited Warranty 10-Year
Environmental Certification RoHS, WEEE Environmentally Friendly Yes Features Intercom/PA Systems, Sound/Audio Systems,N/A to N/A Indoor/Outdoor Indoor
