SoundTube CM52S-BGM-II-WH In-Ceiling Speaker with Magnetic Grill and Short Can, 5.25"
CM52S-BGM-II-WH
|9W-M52SBGMIW
Shop all SoundTube
SoundTube CM52S-BGM-II-WH In-Ceiling Speaker with Magnetic Grill and Short Can, 5.25"
CM52S-BGM-II-WH | 9W-M52SBGMIW
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Engineered for applications with limited plenum space. Incorporates a SoundTube-specific shallow backcan with an installed depth of 3.5 inches. One 5.25 inch (134 mm) polypropylene woofer with rubber surround and one 0.75 inch (19 mm) silk dome tweeter. BroadBeam Ring technology for mid-range clarity and smooth off axis performance. Easy-access six-position tap switch for 25/70.7/100-volt and transformer bypass settings allows for easy ordering, stocking and installation. Tuned port on baffle for added musicality and bass response down to 65 Hz (-10 dB). Reduced amplification costs and maximum efficiency of 84.5 dB sensitivity, 16 ohm impedance. Incorporates a painted steel magnetic seamless grille for lasting durability. Adaptable to material thicknesses ranging from 0.035 inch (0.9 mm) to 1.6 inch (40.6 mm). UL 1480 and 2043 listed.
General Information
Name: SoundTube CM52S-BGM-II-WH In-Ceiling Speaker with Magnetic Grill and Short Can, 5.25"
Category: SoundTube, Pro AV, Commercial Audio, Pro Speakers
UPC Code: 644216226108
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number 9W-M52SBGMIW Brand Name SoundTube Manufacturer Part Number CM52S-BGM-II-WH Product Type Speaker
Maximum Frequency Response 22 kHz Minimum Frequency Response 90 Hz
Color White
Environmental Certification CE, RoHS, UL Environmentally Friendly Yes Features 88.9 mm, BroadBeam Ring technology for mid-range clarity and ultra wide off axis performance, Engineered for applications with limited plenum space incorporating a SoundTube-specific shallow backcan with an installed depth of 3.5", included accessories tile bridge, UL listed 0.5" conduit clamp, Incorporates a steel plated and powder coated angeless magnetic grille for lasting durability and seamless aesthetic (White grille included, but also available in Black), Tuned port on bafe for added musicality and bass response down to 65 Hz (±10 dB)
