Telguard TG-7FM 5G LTE-M Sole Path Communicator for Commercial Fire

TG-7FM | AD-TG7FM

Please sign in to view pricing, availability, and to add to cart.

Overview

Specifications

Documents

Product Overview

The Telguard TG-7FM Multi-Carrier Universal Sole Path 5G LTE-M Commercial Fire Cellular Alarm Communicator is specially designed for panel-powered, sole path, commercial fire applications, offering the best in alarm communications, featuring all 3 major U.S. cellular carriers. The TG-7FM is all about saving time and money. It starts with a 5G LTE-M communicator not only has AT&T, T-Mobile, and Verizon cellular service but also powers off the alarm panel, and costs less to purchase and install than comparable models. Add to that, the reliability of the Telguard products and the features needed to meet all AHJ and UL requirements and you have a fire communicator that will do the job at minimal cost.

Main Features

Certified for use on 5G LTE-M networks for all three major US carriers, AT&T, T-Mobile, and Verizon
Multi-Carrier technology allows it to choose the best performing network, and automatically fail over to the next network if there is an issue
Powers directly from the fire panel’s 12V/24V auxiliary power source
Operates on LTE-M networks, for lower power consumption and better building penetration
Supports virtually all alarm formats using dial capture for universal panel compatibility: Contact ID, SIA, Radionics Modem formats, Pulse 4x2/3x1, DMP, Sonitrol, etc
Link Supervision available in 60- and 5-minut frequencies to meet any AHJ requirements for Sole Path connectivity
UL 2610, UL 864
LEDs on command unit indicate calling station and line status
Stations receive power from command unit, powered by 24V DC

General Information

Name: Telguard TG-7FM 5G LTE-M Sole Path Communicator for Commercial Fire

Category: Telguard, Fire, Fire Control Panels, Alarm Communicators

UPC Code: 702054304508

Country of Origin: United States. Country of origin is subject to change.

Specifications

: ADI Part Number AD-TG7FM Brand Name Telguard Manufacturer Part Number TG-7FM Product Line Telguard Commercial Fire Product Model TG-7FM Product Series TG-7 Fire Product Type Multi-carrier

: Environmental Certification UL Environmentally Friendly Yes Features Connects to panel DACT (dialer) replacing expensive landlines, Operates on 12/24 volt panel power with no AC outlet needed, Selects primary and backup carriers automatically based on performance analysis
