Product Overview
The PNM-C7083RVD is an outdoor vandal rated network camera featuring 2 Channels, with AI & IR in a dome camera form factor. Featuring 2MP X 2 sensors, each at 30fps with a 3~6mm (2x) (107°~56.3°) motorized varifocal lens, Triple codec (H.265/H.264/MJPEG). The IR viewable length is 25m (82ft), and features a USB port for easy installation, Day & Night (ICR), extremeWDR (120dB), DIS, & Handover. Analytics events based on AI engine: Object detection(Person/Face/Vehicle/License plate), IVA (Virtual line/Area, Enter/Exit, Loitering, direction, intrusion), Analytics events : Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Appear/Disappear. FIPS 140-2, micro SD card 512GB, IP66, NEMA4X, IK10. Operating temperature: -40°C~+55°C(-40°F ~ +131°F), Power: PoE+, Metal shielded RJ-45, Hard-coated dome bubble
General Information
Name : Hanwha PNM-C7083RVD/KEX Series x 2MP AI Outdoor IR Vandal Dome IP Camera, 3-6mm Lens, White, TAA Compliant , Hanwha Vision
Category : Dome Cameras
UPC Code :
Country of Origin : Korea. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : SQ-C783RVDKX
Brand Name : Hanwha Vision
Manufacturer : Hanwha Group
Manufacturer Part Number : PNM-C7083RVD/KEX
Product Model : PNM-C7083RVD
Product Name : 2MP X 2 AI IR Outdoor Dome Camera
Product Series : P
Product Type : Network Camera
Weight (Approximate) (g) : 1330
Technical Information
Effective Camera Resolution : 2MP
Field of View : H: 107(Wide)~56.3(Tele) V: 57(Wide)~31.5(Tele) D: 126(Wide)~64.3(Tele)
HD Recording : Yes
Lens Type : Varifocal
Maximum Aperture : f/2.2
Maximum Focal Length (mm) : 6
Maximum Frame Rate : 30 fps
Minimum Focal Length : 3 mm
Night Vision : Yes
Night Vision Type : Infrared
Optical Zoom : 2x
Camera
Night Vision Distance : 82.02 ft
Night Vision Distance (mm) : 25000
Wide Dynamic Range : Yes
Display & Graphics
Color Supported : Color
Effective Camera Resolution (Pixel) : 2000000
Maximum Video Resolution : 1920 x 1080
Number of Sensors : 2
Environmental Conditions
Maximum Operating Temperature : 131°F (55°C)
Maximum Operating Temperature (°F) : 131
Minimum Operating Temperature : -40°F (-40°C)
Minimum Operating Temperature (°F) : -40
Operating Humidity : 95%
Exposure
Longest Shutter Speed : 1/5 Second
Shortest Shutter Speed : 1/12000 Second
Interfaces/Ports
Network (RJ-45) : yes
Lens
Focal Length : 3-6 mm
Lens Included : Yes
Maximum Focal Length : 6 mm
Minimum Aperture : f/3.1
Physical Characteristics
Color : white
Depth : 5.3"
Depth (mm) : 135
Form Factor : Dome
Height : 3.7"
Height (mm) : 93.2
Weight (Approximate) : 2.93 lb
Width : 8.5"
Width (mm) : 215
Projection Lens
Minimum Focal Length (mm) : 3
Storage
Recording Formats : Full HD
Storage Type : Memory Card
Video
Maximum Frame Rate (fps) : 30
Warranty
Limited Warranty : 3 year
Miscellaneous
Features : Back Light Compensation (BLC), Day/Night, Digital Noise Reduction, Gain Control, Motion detection, Privacy Masking, PTZ, SD Card Local Storage, White Balance, Wide Dynamic Range
Impact Protection Rating : IK10
Indoor/Outdoor : outdoor
Ingress Protection Rating : IP66
TAA Compliant : yes
