Hanwha SPA-D1000 IP Audio Module, Built-in 10W Class D Amplifier, White
SPA-D1000
|SQ-SPAD1000
Shop All Hanwha Vision
Hanwha SPA-D1000 IP Audio Module, Built-in 10W Class D Amplifier, White
SPA-D1000 | SQ-SPAD1000
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The Hanwha Vision SPA-D1000 IP Audio Module is a network-based audio solution designed to integrate high-quality audio capabilities into IP surveillance and communication systems. Equipped with a built-in 10W Class D amplifier, the module supports two-way audio applications, voice announcements, and public address (PA) functionality over standard IP networks. Supporting PoE and PoE+, the SPA-D1000 simplifies installation by delivering both power and data through a single Ethernet connection. It also features 1 GB of internal memory, support for MicroSD storage, and compatibility with industry-standard protocols including SIP, ONVIF Profile S, and SUNAPI, making it suitable for a wide range of security and audio integration applications.
Main Features
- Output Level: 6dBV ± 3dB
- Frequency Response: 20Hz-20kHz
- Amplifier: Built in 10W Class D
- Power: PoE (IEEE 8023 af type 1 Class 3), PoE (IEEE 8023 at type 2 Class 4)
- Internal Memory: 1GB
- Supported Protocol: IPv4, HTTP, HTTPS, SIP, mDNS, DNS, NTP, TCP, UDP, DHCP, ARP, ICMP, SNMP(v3)
- TTS: English(US, UK), German, French, Spanish, Russian
- Audio Mornitoring: Speaker, Connection test
General Information
Name: Hanwha SPA-D1000 IP Audio Module, Built-in 10W Class D Amplifier, White
Category: Hanwha Vision, Pro AV, Commercial Audio, Pro Mass Notification
UPC Code: 8801089184382
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number SQ-SPAD1000 Brand Name Hanwha Vision Manufacturer Part Number SPA-D1000
Color White
