Hanwha TNS-9050IBC WISENET Network BCR Barcode Reader Camera
TNS-9050IBC
|SQ-TNS9050IB
Shop All Hanwha Vision
Hanwha TNS-9050IBC WISENET Network BCR Barcode Reader Camera
TNS-9050IBC | SQ-TNS9050IB
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
TNS-9050IBC, Dual Lens BCR Camera Barcode reading cameras, fixed mount Accurate barcode recognition, even on high-speed conveyors.Logistics automation offers greater reliability and reduced mis-delivery as well as increased parcel capacity and optimized resources. Combining barcode data and videos provides efficient parcel tracking and management.
Main Features
- Dual Global Sensor for Barcode Reading and Video Monitoring, MONO 4K 1" COLOR 4K 1"
- AI barcode location search, Track barcodes on high speed conveyor belt moving at 2m/s
- 1D Code is available
- Reinforced durability
- IP66, IP67, IK10, NEMA TS-2 2.2.9, M12 8pin Ethernet connect
- Humidity control with AIR vent, EN 60068-2-6
General Information
Name: Hanwha TNS-9050IBC WISENET Network BCR Barcode Reader Camera
Category: Hanwha Vision, Access Control, Keypads & Readers, Barcode & Document Scanners
UPC Code: 8801089234834
Country of Origin: Korea. Country of origin is subject to change.
Specifications
ADI Part Number SQ-TNS9050IB Brand Name Hanwha Vision Manufacturer Part Number TNS-9050IBC Product Name Dual Sensor BCR Camera Product Type Camera
Field of View Diagonal, Horizontal, Vertical Field of View (Horizontal) 30.4° Field of View (Vertical) 16.60° Maximum Aperture f/16 Maximum Frame Rate 20fps Wide Dynamic Range Yes
Image Sensor Type CMOS
Ingress Protection Rating IP66, IP67
Minimum Operating Temperature -40°F Operating Humidity 0.95
Longest Shutter Speed 1/30 Second Shortest Shutter Speed 1/10000 Second
Lens Included Yes Maximum Focal Length 25.00mm Minimum Aperture f/2.8
Color Black Depth 4.70" Durability Dustproof, Impact Resistant, Waterproof Height 7.10" Weight 7.50lb Width 10.00"
Input Voltage 24V DC
Environmental Certification UL Environmentally Friendly Yes Impact Protection Rating IK10
