AXIS M4216-V M42 Series 4MP Vandal Resistant Fixed Dome WDR IP Camera, 3-6mm Varifocal Lens, White
M4216-V
|Z4-02112001
Shop All Axis Communications
AXIS M4216-V M42 Series 4MP Vandal Resistant Fixed Dome WDR IP Camera, 3-6mm Varifocal Lens, White
M4216-V | Z4-02112001
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Featuring WDR and Lightfinder, this compact and discreet dome delivers great image quality in challenging light conditions. A deep learning processing unit (DLPU) lets you take advantage of intelligent analytics based on deep learning on the edge. Designed to blend into any environment, it can be repainted and offers a range of accessories for discreet monitoring. Plus, it features an HDMI port and the flexibility to add audio and I/O connectivity using AXIS T61 Series. Furthermore, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network.
Specifications
ADI Part Number Z4-02112001 Brand Name AXIS Communications Manufacturer Axis Communications Manufacturer Part Number 02112-001 Product Line M Product Model M4216-V Product Name AXIS M4216-V Product Series M42 Product Type Fixed dome cameras Supported Network Protocols IPv6 USGv6, NIST SP500-267
Aperture f/1.9-2.7 Connectivity Technology Wired Effective Camera Resolution 4MP Field of View Horizontal, Vertical Lens Type Varifocal Maximum Aperture f/1.9 Maximum Frame Rate 30fps Minimum Focal Length 3mm Night Vision Yes Optical Zoom 2x Video Formats H.264, H.265, MJPEG, MPEG-4
Image Sensor Type CMOS Wide Dynamic Range Yes
Ingress Protection Rating IP42 NDAA Compliant Yes TAA Compliant Yes
Image Sensor Size 1/2.7" Maximum Video Resolution 2304 x 1728
Maximum Operating Temperature 113°F (45°C) Minimum Operating Temperature 32°F (0°C) Operating Humidity 0.85 Operating Temperature (T-T) 32-113°F
Longest Shutter Speed 1/5 Second Minimum Illumination 0.03 lux Shortest Shutter Speed 1/37500 Second
HDMI Yes Network (RJ-45) Yes
Focal Length 3-6mm Lens Included Yes Maximum Focal Length 6mm
Memory Card Supported Yes
Remote Management Yes
ADI Part Number Replaces Z4-01240001 Model Number Replaces 01240-001, M4206-V
Color White Durability Vandal Resistant Form Factor Dome Height 2.8" Weight 12.35oz
Maximum Power Consumption 4W Power over Ethernet (PoE) Yes
Diameter 4.8" Mount Type Ceiling Mount, Pendant Mount, Recessed Mount, Surface Mount, Wall Mount
Storage Type Memory Card
Maximum Resolution 1280 x 720
Limited Warranty 5-Year
Certifications CISPR 24, CISPR 35, EAC, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A Certifications & Standards ONVIF G, ONVIF M, ONVIF S, ONVIF T Country of Origin MX Environmental Certification IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC/EN 60529 IP42, IEC/EN 62262 IK08 Features Day/Night, Human Detection, Mirror, Motion Detection, Password Protection, Privacy Masking, PTZ, SD Card Local Storage, Shock Detection, Vehicle Detection, Wide Dynamic Range Impact Protection Rating IK08 Indoor/Outdoor Indoor Package Contents - M4216-V Dome Camera
- Installation Guide
- Windows decoder 1-User License
