Overview

Specifications

Documents

Product Overview

Featuring WDR and Lightfinder, this compact and discreet dome delivers great image quality in challenging light conditions. A deep learning processing unit (DLPU) lets you take advantage of intelligent analytics based on deep learning on the edge. Designed to blend into any environment, it can be repainted and offers a range of accessories for discreet monitoring. Plus, it features an HDMI port and the flexibility to add audio and I/O connectivity using AXIS T61 Series. Furthermore, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network.

Main Features

Analytics with deep learning
Great image quality in 4 MP
HDMI output for public viewing monitors
Lightfinder and WDR
Varifocal lens with remote zoom and focus

General Information

Name: AXIS M4216-V M42 Series 4MP Vandal Resistant Fixed Dome WDR IP Camera, 3-6mm Varifocal Lens, White

Category: Axis Communications, Video Surveillance, IP Cameras, Dome Cameras

UPC Code: 7331021072800

Country of Origin: Mexico. Country of origin is subject to change.

Specifications

ADI Part Number

Z4-02112001

Brand Name

AXIS Communications

Manufacturer

Axis Communications

Manufacturer Part Number

02112-001

Product Line

Product Model

M4216-V

Product Name

AXIS M4216-V

Product Series

M42

Product Type

Fixed dome cameras

Supported Network Protocols

IPv6 USGv6|NIST SP500-267

Weight

12.35oz

Aperture

f/1.9-2.7

Connectivity Technology

Wired

Effective Camera Resolution

4MP

Field of View

Horizontal, Vertical

Lens Type

Varifocal

Maximum Aperture

f/1.9

Maximum Frame Rate

30 fps

Minimum Focal Length

3mm

Night Vision

Yes

Optical Zoom

Video Formats

H.264, H.265, MJPEG, MPEG-4

Image Sensor Type

CMOS

Wide Dynamic Range

Yes

Ingress Protection Rating

IP42

NDAA Compliant

Yes

TAA Compliant

Yes

Image Sensor Size

1/2.7"

Maximum Video Resolution

2304 x 1728

Maximum Operating Temperature

113°F (45°C)

Minimum Operating Temperature

32°F (0°C)

Operating Humidity

85%

Operating Temperature (T-T)

0-45°C

Longest Shutter Speed

1/5 Second

Minimum Illumination

0.03 lux

Shortest Shutter Speed

1/37500 Second

HDMI

Yes

Network (RJ-45)

Yes

Focal Length

3-6mm

Lens Included

Yes

Maximum Focal Length

6 mm

Memory Card Supported

Yes

Remote Management

Yes

ADI Part Number Replaces

Z4-01240001

Model Number Replaces

01240-001, M4206-V

Color

White

Durability

Vandal Resistant

Form Factor

Dome

Height

2.8"

Maximum Power Consumption

Power over Ethernet (PoE)

Yes

Diameter

4.8"

Mount Type

Ceiling Mount, Pendant Mount, Recessed Mount, Surface Mount, Wall Mount

Storage Type

Memory Card

Maximum Resolution

1280 x 720

Limited Warranty

5-Year

Certifications

CISPR 24, CISPR 35, EAC, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A

Certifications & Standards

ONVIF G, ONVIF M, ONVIF S, ONVIF T

Country of Origin

Environmental Certification

IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC/EN 60529 IP42, IEC/EN 62262 IK08

Features

Day/Night, Human Detection, Mirror, Motion Detection, Password Protection, Privacy Masking, PTZ, SD Card Local Storage, Shock Detection, Vehicle Detection, Wide Dynamic Range

Impact Protection Rating

IK08

Indoor/Outdoor

Indoor

Package Contents
