Belden 1583A 004U1000 CAT5e 24/4 Riser Premise Horizontal Cable, 200MHz, U/UTP, Solid BC, PVC Jacket, 1000' UnReel, Yellow
1583A 004U1000
|7B-1583A04U1
Shop All Belden
Belden 1583A 004U1000 CAT5e 24/4 Riser Premise Horizontal Cable, 200MHz, U/UTP, Solid BC, PVC Jacket, 1000' UnReel, Yellow
1583A 004U1000 | 7B-1583A04U1
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
DataConnect Category 5e Premise Horizontal Cable (200MHz), 4 Pair, 24 AWG Solid Bare Copper Conductors, U/UTP, Riser-CMR, PVC Jacket. Ensure maximum network performance and stability in legacy IP applications, renovations and price-sensitive environments with Category 5e cables that exceed standards. Belden offers several Category 5e performance levels. Our top-of-line 1200 Series cable provides headroom beyond the TIA-568-C.2 Category 5e standard and is offered with Bonded-Pair technology to make your installation as robust as possible.
Main Features
- Category 5e Premise Horizontal Cable (200MHz)
- 4 Pair, 24 AWG Solid Bare Copper Conductors
- Unshielded/Unshielded Twisted Pair (U/UTP)
- PO - Polyolefin Insulation
- PVC Jacket
- Indoor
- 300 V (CMR)
- 25 lbs (11 kg) Max. Pull Tension
- 75°C UL Temperature
- China RoHS II (GB/T 26572-2011)
General Information
Name: Belden 1583A 004U1000 CAT5e 24/4 Riser Premise Horizontal Cable, 200MHz, U/UTP, Solid BC, PVC Jacket, 1000' UnReel, Yellow
Category: Belden, Wire & Cable, Network Cables, Category 5e Network Cables
UPC Code: 612825117858
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-1583A04U1 Application/Usage Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, POE, PoE+, PoE++, Premise Horizontal Cable Brand Name Belden Country of Origin MX Manufacturer Part Number 1583A 004U1000 Packaged Quantity 305 PoE Standard PoE++ Product Line DataConnect
American Wire Gauge 24AWG Cable Rating Riser Cable Style Unshielded Cable Type Category 5e Conductor Count 8 Conductor Material Bare Copper CPR Euroclass Rating Eca,EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 Fiber Category OM3 Number of Conductors 8 Number of Pairs 4 Shielding No Solid or Stranded Solid
Certifications & Standards CMR,NEMA WC-63.1,Article 800,ANSI/TIA-568.2-D Category 5e,IEC 60332-1-2,IEEE 802.3bt Type 1, Type 2, Type 3,Riser,CMR,China RoHS II (GB/T 26572-2011),FT4,Yes,CMR,China RoHS II (GB/T 26572-2011),IEC 60332-1-2,IEEE 802.3bt Type 1, Type 2, Typ UL Listed Yes
Operating Temperature (T-T) 0°C to +50°C Storage Temperature (T-T) -20°C to +75°C
Network Technology 100Base-T, 10Base-T
Communication Technology Ethernet
Cable Length 1000' Color Yellow Height 1000.0' Insulation Material Polyolefin,PE (Polyethylene),PP (Polypropylene) Jacket Material Polyolefin,PE (Polyethylene,PP (Polypropylene)
Voltage Rating 300V
Length 1000'
Features Premise Horizontal Cable,N/A to N/A Indoor/Outdoor Indoor
