Belden 1585A 010500 CAT5e Plenum Cable, 24/4 Solid BC, Unshielded, UTP, CMP, 500' (152.4m) Reel, Black
1585A 010500|7B-1585A0105
Belden 1585A 010500 CAT5e Plenum Cable, 24/4 Solid BC, Unshielded, UTP, CMP, 500' (152.4m) Reel, Black
1585A 010500|7B-1585A0105
Key Features
- Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE++, PoE+, PoE
- Size 24 AWG
- Stranding: Solid
Key Features
- Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE++, PoE+, PoE
- Size 24 AWG
- Stranding: Solid
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE++, PoE+, PoE
- Size 24 AWG
- Stranding: Solid
Belden
Belden 1585A 010500 CAT5e Plenum Cable, 24/4 Solid BC, Unshielded, UTP, CMP, 500' (152.4m) Reel, Black
1585A 010500 | 7B-1585A0105
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Introducing the Belden 1585A 010500 CAT5e Plenum Cable, a reliable choice for your networking needs. This high-quality cable comes on a 500-foot reel in black. It's designed for premise horizontal cabling, supporting Ethernet standards including 1000BASE-T, 100BASE-TX, and 10BASE-T, alongside Power over Ethernet applications such as PoE, PoE+, and PoE++. The cable features 24 AWG solid bare copper conductors, ensuring excellent conductivity. With four pairs of conductors, it's ideal for efficient and stable data transmission. Upgrade your network infrastructure today with this durable and efficient cable.
Main Features
- Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE++, PoE+, PoE
- Size 24 AWG
- Stranding: Solid
- Material: BC - Bare Copper (High Conductivity)
- Number of Pairs: 4
General Information
Name: Belden 1585A 010500 CAT5e Plenum Cable, 24/4 Solid BC, Unshielded, UTP, CMP, 500' (152.4m) Reel, Black
Category: Belden, Wire & Cable, Network Cables, Category 5e Network Cables
UPC Code: 612825118404
Country of Origin: . Country of origin is subject to change.
Specifications
-
ADI Part Number 7B-1585A0105 Brand Name Belden Manufacturer Belden CDT, Inc Manufacturer Part Number 1585A 010500 Product Name CAT5E 4PR U/UTP CMP REEL Product Type Network Cable
-
American Wire Gauge 24AWG Cable Rating Plenum Cable Type Category 5e Conductor Count 4 Conductor Material Copper Device Supported Network Device Jacket Material LS PVC Jacket Type Plenum Number of Conductors 8 Number of Pairs 4 Shielding No Solid or Stranded Solid
-
Data Transfer Rate 1 Gbit/s
-
Cable Length 500' Color Black Insulation Material PE Material Copper Package Type Reel
-
Environmental Certification China RoHS, China RoHS 2, ELV, EU RoHS, EU WEEE, RoHS, RoHS 2 Environmentally Friendly Yes Features Attenuation to Crosstalk Ratio (ACR), Bendable, Equal Level Far End Crosstalk (ELFEXT), Minimized Near-End Crosstalk (NEXT), PoE, PoE+, Power Sum Attenuation to Crosstalk Ratio (PSACR), Power-sum Equal Level Far End Crosstalk Loss (PSELFLEXT), Power-sum Near End Crosstalk (PSNEXT)
