Hanwha XNB-8003/KEX Series 6MP AI Box IP Camera, Lens Not Included, Black, TAA Compliant
XNB-8003/KEX|SQ-XB8003KEX
Hanwha XNB-8003/KEX Series 6MP AI Box IP Camera, Lens Not Included, Black, TAA Compliant
XNB-8003/KEX|SQ-XB8003KEX
Key Features
- 6MP resolution
- Color 0.03 Lux (F1.2, 1/30sec, 30IRE), BW: 0.003 Lux (F1.2, 1/30sec, 30IRE)
- Maximum 30 fps (H.265/H.264)
Key Features
- 6MP resolution
- Color 0.03 Lux (F1.2, 1/30sec, 30IRE), BW: 0.003 Lux (F1.2, 1/30sec, 30IRE)
- Maximum 30 fps (H.265/H.264)
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- 6MP resolution
- Color 0.03 Lux (F1.2, 1/30sec, 30IRE), BW: 0.003 Lux (F1.2, 1/30sec, 30IRE)
- Maximum 30 fps (H.265/H.264)
Hanwha Vision
Hanwha XNB-8003/KEX Series 6MP AI Box IP Camera, Lens Not Included, Black, TAA Compliant
XNB-8003/KEX | SQ-XB8003KEX
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The new X series cameras utilize AI to detect and classify people, vehicles, faces, license plates and more in real-time. With a range of available resolutions from 2MP to 4K, the cameras' deep-learning algorithms can reliably identify multiple distinct objects. Reduce false alarms due to none interesting motion, like wind-blown trees, shadows, or animals. Analytics become a reliable second pair of eyes to operators helping them know where to look for important real-time events, while making post-event forensic searches highly efficient.
Main Features
- 6MP resolution
- Color 0.03 Lux (F1.2, 1/30sec, 30IRE), BW: 0.003 Lux (F1.2, 1/30sec, 30IRE)
- Maximum 30 fps (H.265/H.264)
- Day and Night (ICR), extremeWDR (120dB)
- WiseNR(Based on AI engine), WiseStream III(Based on AI engine)
- Analytics events based on AI engine (NPU): Object detection (Person/Face/Vehicle - car, truck, bus, bicycle, motorcycle/License plate)
- IVA (Virtual line/Area, Enter/Exit, Loitering, Direction, Intrusion)
- Analytics events, Defocus detection, Motion detection, Tampering, Fog detection
- Audio detection, Sound classification, Shock detection, Appear/Disappear
General Information
Name: Hanwha XNB-8003/KEX Series 6MP AI Box IP Camera, Lens Not Included, Black, TAA Compliant
Category: Hanwha Vision, Video Surveillance, IP Cameras, Box Cameras
UPC Code: 8801089207722
Country of Origin: Korea. Country of origin is subject to change.
Specifications
-
ADI Part Number SQ-XB8003KEX Brand Name Hanwha Vision Manufacturer Hanwha Vision Manufacturer Part Number XNB-8003/KEX Product Model XNB-8003/KEX Product Name 6MP Box AI Camera Product Series X Product Type Box Camera Weight 1.94 lb
-
Connectivity Technology Wired Effective Camera Resolution 6MP Lens Type DC Auto Iris, I-CS, Manual, P-iris Maximum Aperture f/1.2 Maximum Frame Rate 30 fps Video Formats H.264, H.264H, H.265, H.265M, MJPEG
-
Image Sensor Type CMOS Wide Dynamic Range Yes
-
TAA Compliant Yes
-
Maximum Video Resolution 3328 x 1872
-
Maximum Operating Temperature 131°F Minimum Operating Temperature -14°F Operating Humidity <95% RH (Non Condensing)
-
Longest Shutter Speed 1/12000 Second Minimum Illumination 0.003 lux Shortest Shutter Speed 2 Second
-
Network (RJ-45) Yes
-
Lens Included Yes
-
Remote Management Yes
-
Color Black Depth 6.48" Height 2.64" Width 3.19"
-
Input Voltage 12V DC
-
Mount Type Box Mount, C-Mount, CS-Mount
-
Storage Type Memory Card
-
Analog Video Signal Format CVBS Maximum Resolution 1280 x 720
-
Limited Warranty 3-Year
-
Country of Origin KR Features Back Light Compensation (BLC), Day/Night, Defog, Digital Noise Reduction, Face Detection, Fog Reduction, Highlight Compensation (HLC), Motion Detection, Privacy Masking, Shock Detection, Tamper Detection, Vehicle Detection, Wide Dynamic Range
