AXIS P1375-E P13 Series 2MP Outdoor Fixed WDR Box IP Camera, 2.8-8mm Lens, White

Brand: AXIS Communications
ADI #:Z4-01533001 Model #: 01533-001  Name: AXIS P1375-E P13 Series 2MP Outdoor Fixed WDR Box IP Camera, 2.8-8mm Lens, White
  • HDTV 1080p at up to 60 fps
  • Electronic image stabilization and IK10
  • Signed firmware and secure boot
AXIS P1375-E 2 Megapixel Network Camera
Lens

Product Overview

With a robust design, AXIS P1375-E Network Camera offers excellent video for outdoor scenes. It handles temperatures between -40 °C to 60 °C (-40 °F to 140 °F) and delivers details even in challenging light conditions or low-light, with Forensic WDR and Lightfinder 2.0. For pitch darkness, an optional IR kit is available. Enhanced security features such as signed firmware and secure boot ensure the integrity and authenticity of the camera's firmware. Furthermore, tampering alarm and video streaming indicator ensure full control of the video. With CS mount and built-in camera rails, a bigger variety of lenses can be used.

General Information

Name : AXIS P1375-E P13 Series 2MP Outdoor Fixed WDR Box IP Camera, 2.8-8mm Lens, White , AXIS Communications
Category : Box Cameras
UPC Code : 7331021064638
Country of Origin : Thailand. Country of origin is subject to change.

Specifications

General Information

ADI Part Number : Z4-01533001
Brand Name : AXIS
Connectivity Technology : Wired
Manufacturer : Axis Communications
Manufacturer Part Number : 01533-001
NDAA Compliant : Yes
Product Model : P1375-E
Product Name : P1375-E Network Camera
Product Series : P13
Product Type : Network Camera
Weight (Approximate) (g) : 2200

Technical Information

Effective Camera Resolution : 2MP
Field of View : Horizontal field of view: 107°-42° - Vertical field of view: 57°-24°
HD Recording : Yes
Lens Mount Type : CS Mount
Lens Type : Varifocal
Maximum Aperture : f/1.2
Maximum Focal Length (mm) : 8
Maximum Frame Rate : 60 fps
Minimum Focal Length : 2.8 mm
Optical Zoom : 3.5x
Video Formats : H.264, H.265, MJPEG, MPEG-4

Camera

Image Sensor Type : CMOS
Wide Dynamic Range : Yes

Display & Graphics

Color Supported : Color
Effective Camera Resolution (Pixel) : 2000000
Maximum Video Resolution : 1920 x 1080
Minimum Illumination (lux) : 0

Environmental Conditions

Maximum Operating Temperature : 140°F (60°C)
Maximum Operating Temperature (°F) : 140
Minimum Operating Temperature : -40°F (-40°C)
Minimum Operating Temperature (°F) : -40
Operating Humidity : 100%

Exposure

Longest Shutter Speed : 2 Second
Minimum Illumination : 0 lux
Shortest Shutter Speed : 1/66500 Second

Interfaces/Ports

Network (RJ-45) : Yes

Lens

Focal Length : 8 mm
Lens Included : Yes
Maximum Focal Length : 8 mm

Network & Communication

Remote Management : Yes

Physical Characteristics

Color : White
Depth : 15.9"
Depth (mm) : 404
Durability : Dust Resistant, Impact Resistant, Rain Resistant, Snow Resistant, Vandal Resistant, Water Resistant, Weather Resistant
Form Factor : Box
Height : 5.6"
Height (mm) : 143
Weight (Approximate) : 4.85 lb
Width : 6.3"
Width (mm) : 159

Power Description

Input Voltage : 28 V DC
Input Voltage (V DC) : 28

Product Information

Mount Type : Backbox Mount, Bracket Mount, Ceiling Mount, Column Mount, Conduit Mount, Corner Mount, Pole Mount, Wall Mount

Projection Lens

Minimum Focal Length (mm) : 2.8

Storage

Recording Formats : Full HD
Storage Type : Memory Card

Video

Maximum Frame Rate (fps) : 60

Warranty

Limited Warranty : 5 Year

Miscellaneous

Country of Origin : Thailand
Features : Day/Night, Defog, Electronic Image Stabilization, Microphone In, Privacy Masking, PTZ, Removable IR Cut-off Filter, Tampering Alarm, White Balance, Wide Dynamic Range
Impact Protection Rating : IK10
Indoor/Outdoor : Outdoor
Ingress Protection Rating : IP66, IP67
