Hanwha XNV-8040R X-Series 5MP IR Outdoor Vandal Dome Camera, 7mm Fixed Lens, Ivory
XNV-8040R|SQ-XNV8040R
Hanwha XNV-8040R X-Series 5MP IR Outdoor Vandal Dome Camera, 7mm Fixed Lens, Ivory
XNV-8040R|SQ-XNV8040R
Key Features
- Built-in 7 mm fixed lens
- Max. 30 fpsatall resolutions (H.265/H.264)
- Loitering, Directional detection, Fog detection, Digital auto tracking, Sound classification, Heatmap, People counting, Queue management, Tampering
Key Features
- Built-in 7 mm fixed lens
- Max. 30 fpsatall resolutions (H.265/H.264)
- Loitering, Directional detection, Fog detection, Digital auto tracking, Sound classification, Heatmap, People counting, Queue management, Tampering
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- Built-in 7 mm fixed lens
- Max. 30 fpsatall resolutions (H.265/H.264)
- Loitering, Directional detection, Fog detection, Digital auto tracking, Sound classification, Heatmap, People counting, Queue management, Tampering
Hanwha Vision
Hanwha XNV-8040R X-Series 5MP IR Outdoor Vandal Dome Camera, 7mm Fixed Lens, Ivory
XNV-8040R | SQ-XNV8040R
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
X series features the most powerful chipset ever incorporated into a full camera range. Hanwha’s self-developed 5 chip uses an all-new architecture that enables faster processing. This means the highest quality video performance with essential features suited to a wide range of video surveillance applications.
Main Features
- Built-in 7 mm fixed lens
- Max. 30 fpsatall resolutions (H.265/H.264)
- Loitering, Directional detection, Fog detection, Digital auto tracking, Sound classification, Heatmap, People counting, Queue management, Tampering
- Motion detection, Handover
- Hallway view, WiseStreamII support
- IR viewable length 30m, IP67/IP66, IK10
General Information
Name: Hanwha XNV-8040R X-Series 5MP IR Outdoor Vandal Dome Camera, 7mm Fixed Lens, Ivory
Category: Hanwha Vision, Video Surveillance, IP Cameras, Dome Cameras
UPC Code: 8801089095510
Country of Origin: +1. Country of origin is subject to change.
Specifications
-
ADI Part Number SQ-XNV8040R Brand Name Hanwha Vision Manufacturer Hanwha Group Manufacturer Part Number XNV-8040R Product Model XNV-8040R Product Name 5M Vandal-Resistant Network IR Dome Camera Product Series X Product Type Network Camera Weight 1.36 lb
-
Connectivity Technology Wired Effective Camera Resolution 5MP Lens Type Fixed Maximum Aperture f/1.6 Maximum Frame Rate 30 fps Minimum Focal Length 7mm Video Formats H.264, H.265, MJPEG, MPEG-4
-
Image Sensor Type CMOS Night Vision Distance 98.43 ft Wide Dynamic Range Yes
-
Ingress Protection Rating IP66, IP67 NDAA Compliant Yes
-
Maximum Video Resolution 1600 x 1200
-
Network (RJ-45) Yes
-
Focal Length 7 mm Maximum Focal Length 7 mm
-
Remote Management Yes
-
Color White Durability Dustproof, Impact Resistant, Waterproof Form Factor Dome Height 3.8"
-
Diameter 4.7" Mount Type Corner Mount, Pole Mount, Wall Mount
-
Recording Formats HD
-
Maximum Resolution 1280 x 720
-
Limited Warranty 3-Year
-
Impact Protection Rating IK10 Indoor/Outdoor Outdoor
