Hanwha XNP-9250R/KAP Series 4K IR PTZ Plus IP Camera, 25x Optical Zoom Lens, Black/White, TAA Compliant
XNP-9250R/KAP|SQ-XP925RKAP
Hanwha XNP-9250R/KAP Series 4K IR PTZ Plus IP Camera, 25x Optical Zoom Lens, Black/White, TAA Compliant
XNP-9250R/KAP|SQ-XP925RKAP
Key Features
- Maximum 4K resolution
- 5~125 mm (25x) Optical zoom (digital 32x, total 800x zoom)
- Maximum IR viewable length 200m (Wise IR)
Key Features
- Maximum 4K resolution
- 5~125 mm (25x) Optical zoom (digital 32x, total 800x zoom)
- Maximum IR viewable length 200m (Wise IR)
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- Maximum 4K resolution
- 5~125 mm (25x) Optical zoom (digital 32x, total 800x zoom)
- Maximum IR viewable length 200m (Wise IR)
Hanwha Vision
Hanwha XNP-9250R/KAP Series 4K IR PTZ Plus IP Camera, 25x Optical Zoom Lens, Black/White, TAA Compliant
XNP-9250R/KAP | SQ-XP925RKAP
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
PTZ PLUS supports remarkable performance with new in-house developed 4K 25x zoom lens. Experience powerful new PTZ’s performance. PTZ PLUS supports object (person or vehicle) auto tracking based on AI deep-learning algorithm. And by simply right-clicking an object on a screen, it locks the object and tracks the targeted object. (target-lock tracking). PTZ PLUS allows for monitoring in complete darkness up to 200meters with Wise IR. It optimizes amount of IR at every zoom ratio.
Main Features
- Maximum 4K resolution
- 5~125 mm (25x) Optical zoom (digital 32x, total 800x zoom)
- Maximum IR viewable length 200m (Wise IR)
- Day and night (ICR), extreme WDR (120dB), DIS (Built-in gyro sensor)
- Intelligent analytics, object auto tracking (person, vehicle), target lock tracking
- H.264, H.265, MJPEG codec, WiseStreamII
- IP66, IK10, NEMA4X, NEMA-TS 2 (2.2.8, 2.2.9)
- PTZ PLUS Design applied (Compact, Lighter, Simple cabling)
- SFP-supported by injector
General Information
Name: Hanwha XNP-9250R/KAP Series 4K IR PTZ Plus IP Camera, 25x Optical Zoom Lens, Black/White, TAA Compliant
Category: Hanwha Vision, Video Surveillance, IP Cameras, PTZ Security Cameras
UPC Code: 8801089200006
Country of Origin: Korea. Country of origin is subject to change.
Specifications
-
ADI Part Number SQ-XP925RKAP Brand Name Hanwha Vision Manufacturer Hanwha Vision Manufacturer Part Number XNP-9250R/KAP Product Model XNP-9250R/KAP Product Name 4K, 25x, IR PTZ camera Product Series X Product Type PTZ Camera Weight 7.05 lb
-
Connectivity Technology Wired Effective Camera Resolution 8mp Field of View H: 57.42°(Wide)~2.71°(Tele) / V: 33.54°(Wide)~1.55°(Tele) Lens Type DC Auto Iris Maximum Aperture F1.6 Maximum Frame Rate 30 fps Minimum Focal Length 5 mm Night Vision Yes Night Vision Type Infrared Optical Zoom 25x Video Formats H.264, H.264B, H.264H, H.264M, H.265, H.265B, H.265H, H.265M, MJPEG
-
Image Sensor Type CMOS Night Vision Distance 656.17 ft Wide Dynamic Range Yes
-
Ingress Protection Rating IP66 TAA Compliant Yes
-
Maximum Video Resolution 3840 x 2160
-
Maximum Operating Temperature 131°F Minimum Operating Temperature -40°F Operating Humidity <95% RH (Non Condensing)
-
Longest Shutter Speed 1/12000 Second Minimum Illumination 0.1 lux Shortest Shutter Speed 2 Second
-
Network (RJ-45) Yes
-
Focal Length 5-125 mm Lens Included Yes Maximum Focal Length 125 mm Minimum Aperture f/3.73
-
Remote Management Yes
-
Color Black, White Durability Dustproof, Impact Resistant, Waterproof Form Factor PTZ
-
Diameter 6.2" Mount Type Desktop Mount, Rack Mount, Wall Mount
-
Recording Formats 4K Storage Type Memory Card
-
Maximum Resolution 1280 x 720
-
Limited Warranty 3-Year
-
Country of Origin KR Features Audio Detection, Back Light Compensation (BLC), Day/Night, Defog, Digital Image Stabilization, Digital Noise Reduction, Gain Control, Motion Detection, Privacy Masking, PTZ, White Balance, Wide Dynamic Range Impact Protection Rating IK10
