Belden 1506A 0071000 RG59 Coaxial Video Cable, 75 ohm SDI Coax, 20 AWG Solid Bare Copper Conductor, FEP Insulation, Foil 95% Tinned Copper Braid Shield, PVC Jacket, CMP, 1000' (152.4m) Reel, Violet

Brand: Belden
ADI #:7B-1506A0071 Model #: 1506A 0071000  Name: Belden 1506A 0071000 RG59 Coaxial Video Cable, 75 ohm SDI Coax, 20 AWG Solid Bare Copper Conductor, FEP Insulation, Foil 95% Tinned Copper Braid Shield, PVC Jacket, CMP, 1000' (152.4m) Reel, Violet
  • Offers exceptional quality and great compatibility with video equipment
  • Coaxial cable for environment requiring moderate coverage and low bandwidth
  • Durable material offers flame retardancy
Image of 7B-1506A0071

Product Overview

General Information

Name : Belden 1506A 0071000 RG59 Coaxial Video Cable, 75 ohm SDI Coax, 20 AWG Solid Bare Copper Conductor, FEP Insulation, Foil 95% Tinned Copper Braid Shield, PVC Jacket, CMP, 1000' (152.4m) Reel, Violet , Belden
Category : Coaxial Cables
UPC Code : 612825116639

Specifications

General Information

ADI Part Number : 7B-1506A0071
Brand Name : Belden
Manufacturer : Belden CDT, Inc
Manufacturer Part Number : 1506A 0071000
Product Name : 75 Ohm SDI Coax, RG-59, 20 AWG Solid BC, Foil + 95% TC Braid, PVC Jkt, CMP
Product Type : Video Cable

Technical Information

American Wire Gauge : 22AWG
Cable Type : Coaxial
Device Supported : HDTV, Video Device
Impedance : 75 ohms
Jacket Type : FT6, Plenum
Material : PVC
Number of Conductors : 1
Shielding : Yes
Supported Resolution : 1920 x 1080

Physical Characteristics

Cable Length : 1000'
Cable Length (mm) : 304800
Color : Purple
Insulation Material : FFEP
Package Type : Reel

Miscellaneous

Environmental Certification : China RoHS 2, EU RoHS, EU WEEE, REACH, RoHS 2
Environmentally Friendly : Yes
Features : Flame Retardant
