ADI PRO RN-7001108 RG6 Quad-Shielded CATV Cable, 60% AL 40% AL Braid, 18/1 CCS, Non-Plenum, 1000' (304.8m) Pull Box, Black
Brand: ADI PRO
ADI #:RN-7001108
Model #: RN-7001108
Name: ADI PRO RN-7001108 RG6 Quad-Shielded CATV Cable, 60% AL 40% AL Braid, 18/1 CCS, Non-Plenum, 1000' (304.8m) Pull Box, Black
- 18 AWG copper-clad steel conductor
- Foam PE
- 60% plus 40% aluminum braid
Sale Type: ADI Choice
Product Overview
Our 1,000 ft Quad-Shielded Coaxial Cable is constructed of 18AWG with a copper clad steel conductor providing a higher level of shielding for signal retention. Great for various applications such as CCTV, Audio/Video and data communications. With the incredible flexibility of the wire, it makes it very easy to install while providing high quality images. Available in white and black color, UL listed and supports CL2 guidelines.
General Information
Name : ADI PRO RN-7001108 RG6 Quad-Shielded CATV Cable, 60% AL 40% AL Braid, 18/1 CCS, Non-Plenum, 1000' (304.8m) Pull Box, Black , ADI PROCategory : Coaxial Cables
UPC Code : 840049304284
Country of Origin : Vietnam. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : RN-7001108
Brand Name : ADI PRO
Manufacturer : ADI PRO
Manufacturer Part Number : RN-7001108
Product Line : Siamese
Product Name : RG6 Quad-Shielded CATV, Non-Plenum 18 AWG CCS, 1000' (304.8m) Pull Box, Black
Product Type : Control Cable
Technical Information
American Wire Gauge : 18 AWG
Cable Type : Coaxial
Connector on First End : Bare Wire
Connector on Second End : Bare Wire
Device Supported : Audio/Video Device, Security Device
Impedance : 75 Ohms
Jacket Type : CL2, CM
Number of Conductors : 1
Shielding : Yes
Physical Characteristics
Cable Length : 1000 ft
Cable Length (mm) : 304800
Color : Black
Package Type : Pull Box
Miscellaneous
Country of Origin : Vietnam
Environmental Certification : RoHS
Environmentally Friendly : Yes
Features : Flexible
