Genesis 41531008 14/2 Stranded Unshielded Fire Alarm Cable, Direct Burial, FPL, CL3, 1000' (304.8 m) Reel, Black
41531008|WG-41531008
Genesis 41531008 14/2 Stranded Unshielded Fire Alarm Cable, Direct Burial, FPL, CL3, 1000' (304.8 m) Reel, Black
41531008|WG-41531008
Key Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- SRPVC insulation
- PVC jacket
Key Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- SRPVC insulation
- PVC jacket
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- SRPVC insulation
- PVC jacket
Genesis
Genesis 41531008 14/2 Stranded Unshielded Fire Alarm Cable, Direct Burial, FPL, CL3, 1000' (304.8 m) Reel, Black
41531008 | WG-41531008
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Genesis Fire Alarm Cables ensure uninterrupted fire protection. Built to exceed the demands of rigorous fire safety codes and regulations, UL listed, and Made in the USA.
Main Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- SRPVC insulation
- PVC jacket
- Durable rip cord for efficient jacket stripping and removal
- Countdown Length Markings for easy tracking of usage and remaining cable
- Rated for 300 Volts
- Rated for -20 °C to 75 °C
- Sunlight Resistant (UV) Rated
- REACH/RoHS Compliant
General Information
Name: Genesis 41531008 14/2 Stranded Unshielded Fire Alarm Cable, Direct Burial, FPL, CL3, 1000' (304.8 m) Reel, Black
Category: Genesis, Wire & Cable, Fire & Life Safety Cables, FPL Unshielded Cables
UPC Code: 619172060394
Country of Origin: United States. Country of origin is subject to change.
Specifications
-
ADI Part Number WG-41531008 Brand Name Genesis Manufacturer Genesis Cable Manufacturer Part Number 41531008 Packaged Quantity 1 Product Model 41531008 Product Name 4153-10-08 Control Cable Product Type Fire Alarm Cable Weight 59 lb
-
American Wire Gauge 14AWG Cable Rating Outdoor|Riser Conductor Count 2 Conductor Material Bare Copper Connector on First End Bare Wire Connector on Second End Bare Wire Core/Cladding Diameter 14/2 Device Supported Alarm, Fire Alarm Jacket Material PVC Jacket Type Outdoor, Riser Number of Conductors 2 Number of Pairs 1 Shielding No Solid or Stranded Stranded
-
TAA Compliant Yes
-
Cable Length 1000' Color Black Insulation Material SRPVC Material Bare Copper Package Type Reel
-
Limited Warranty 3-Year
-
Country of Origin US Environmental Certification RoHS Features Stranded Indoor/Outdoor Outdoor
