Product Overview
EdgeMax loudspeakers combine bold surface-mount performance with stealthy design to shatter the limitations of traditional in-ceiling loudspeakers. Patented PhaseGuide technology enables EdgeMax loudspeakers to project powerful, focused sound asymmetrically from the room's edges to the center. New EdgeMax LP models feature an 80° vertical coverage angle for use in rooms with lower ceilings, and their shallow 4" backcan is ideal for spaces with above-ceiling limitations and tighter clearances. Larger rooms with higher SPL needs benefit from the powerful, deeper 9" cans and 75° vertical coverage of the original EdgeMax models. EdgeMax models are purpose-built to provide specific horizontal coverage. The EM180-LP's 180° horizontal coverage angle makes it ideal for placement along the ceiling edge. It provides a wide and consistent sound pattern optimized for near-field applications and room-filling coverage. Integrators can "mix and match" original EdgeMax and new LP loudspeakers, particularly in challenging installations with varying space dimensions and above-ceiling obstructions.
Main Features
- Patented PhaseGuide technology
- In-ceiling installation for minimum visual impact, with fewer units required to deliver uniform sound
- High-frequency compression driver and high-excursion woofer for exceptional audio quality and power
- Wall-boundary loading for greater bass response and performance
- Consistent voicing across the EdgeMax family
- QuickHold spring-loaded mounting system for easy installs
- Magnetically attached grille for quick access to wiring and tap settings
- Shallow 4" (10cm) backcan height for rooms with above-ceiling limitations and tighter clearances
- 80° Vertical coverage angle for use in rooms with lower ceilings
- 2-Way passive crossover with bypassable 70/100V transformer
General Information
Name: Bose Professional EM180-LP's EdgeMax 180-Degree Horizontal Loud Speaker
Category: Bose Professional, Pro AV, Commercial Audio, Pro Speakers
UPC Code: 017817855754
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number 1B-891454020 Brand Name Bose Professional Manufacturer Part Number 891454-0200 Product Line EdgeMax Product Model EM180-LP Product Series EM
Application/Usage Atriums & Cafeterias, Conference rooms, Halls, Hospitality spaces, Restaurants, Retail, Retrofits Crossover Type 2-way Impedance 8 ohms Material Plastic Sensitivity 91dB
Maximum Frequency Response 18000Hz Minimum Frequency Response 50Hz
Depth 0.5" Weight 16.7lb Width 15.4"
Environmental Certification UL Listed Package Contents 1 adjustable tile bridge, 1 ceiling hole template, 1 EdgeMax EM180-LP, 1 Installation Guide, 1 paint shield
