APC GVSUPS20KFS Galaxy VS UPS 20kW 208V for External Batteries, Start-Up 5x8
GVSUPS20KFS
|2G-SUPS20KFS
Shop All APC by Schneider Electric
APC GVSUPS20KFS Galaxy VS UPS 20kW 208V for External Batteries, Start-Up 5x8
GVSUPS20KFS | 2G-SUPS20KFS
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Highly efficient, easy-to-deploy 20kW, 208V 3-Phase uninterruptible power supply (UPS) that brings best-in-class power protection to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. Compact design, high-density technology and modular architecture keep total cost of ownership low and operational efficiency at the highest levels. Galaxy VS reduces your energy losses by up to 66% with the patented ECOnversion mode, reaching up to 99% efficiency levels and delivering more energy savings than even our industry-leading 97% efficiency in normal operating mode. The UPS is EcoStruxure-ready to give you peace of mind with cloud-based remote monitoring and management via your smartphone. Includes 5x8 start-up service.
Specifications
ADI Part Number 2G-SUPS20KFS Brand Name APC by Schneider Electric Manufacturer Schneider Electric SA Manufacturer Part Number GVSUPS20KFS Product Line Galaxy VS Product Name Galaxy VS 20kW Tower UPS Product Type Double Conversion Online UPS
Application/Usage Business, Critical System, Data Center Output Voltage 200V AC, 208V AC, 220V AC Phase Three Phase Receptacle Detail 1 x Hard Wire 4-wire (3P + E), 1 x Hard Wire 5-wire (3P + N + E) Receptacle Type Hard Wire 4-wire (3P + E), Hard Wire 5-wire (3P + N + E)
Maximum Storage Relative Humidity 0.8
Maximum Operating Elevation 3281' Maximum Operating Temperature 104°F (40°C) Maximum Storage Elevation 15240' Thermal Dissipation 1177.79W
Depth 33.3" Form Factor Tower Height 58.5" Weight 462.97lb Width 20.5"
Input Frequency 70Hz Input Voltage 177-239V AC Output Frequency 60Hz Plug/Connector Type Hard Wire 5-wire (3P + N + E) Waveform Type Sine Wave
Limited Warranty 1-Year
Country of Origin IN Environmentally Friendly Yes Package Contents - Galaxy VS 20kW Tower UPS
- Dust Filter
- Installation Guide
- Integrated Network Management
- Power Modules Ship Installed
- Start-up Service
- Top and Bottom Cable Entry
