APC GVSUPS20KRGS Galaxy VS UPS 20kW 480V with N+1 Power Module for External Batteries, Start-Up 5x8
GVSUPS20KRGS
|2G-UPS20KRGS
Shop All APC by Schneider Electric
APC GVSUPS20KRGS Galaxy VS UPS 20kW 480V with N+1 Power Module for External Batteries, Start-Up 5x8
GVSUPS20KRGS | 2G-UPS20KRGS
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Highly efficient, easy-to-deploy 20kW, 480V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. Includes 5x8 start-up service and one additional power module for N+1 redundancy.
Main Features
- 20kW, 480V 3-phase UPS
- Best-in-class power protection
- Low total cost of ownership
- Ideal for edge, small & medium data centers
- Suitable for commercial & industrial use
- Includes 5x8 start-up service
- N+1 redundancy with extra power module
- Highly efficient & easy to deploy
General Information
Name: APC GVSUPS20KRGS Galaxy VS UPS 20kW 480V with N+1 Power Module for External Batteries, Start-Up 5x8
Category: APC by Schneider Electric, Batteries & Power Supplies, Power Management, UPS
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 2G-UPS20KRGS Application/Usage Commercial, Data Center, Industrial, Infrastructure Brand Name APC by Schneider Electric Manufacturer Part Number GVSUPS20KRGS Product Name Galaxy VS UPS 20kW 480V with N+1 power module for external batteries, Start-up 5x8 Product Type Double Conversion Online UPS
Output Voltage 480V Software Included Yes
Battery Characteristics VRLA Battery Chemistry Lithium-Ion (Li-ion)
Maximum Operating Elevation 3300.0000' Maximum Operating Temperature 104.00°F Thermal Dissipation 641.23W
Depth 33.30" Height 58.50" Weight 551.20lb Width 20.50"
Input Frequency 70Hz Input Voltage 480V Output Frequency 60Hz Waveform Type Pure Sine Wave
Limited Warranty 1-Year
Environmental Certification China RoHS, FCC, Green Premium, REACH, RoHS, UL Environmentally Friendly Yes
