Product Overview
Easily distribute a single Ultra-High-Definition (UHD) signal to multiple displays.
The Manhattan 4K 4-Port HDMI Splitter with built-in booster streams a 4K HDMI signal from a single UHD source to up to four UHD displays.
Best Possible Image Quality and Easy Installation
Full compliance with HDMI and HDCP 1.4 ensures the Manhattan 4K 4-Port HDMI Splitter provides nothing short of high-quality performance and reliability. It delivers cinematic 4K resolution and supports 3D video, Deep Color, as well as LPCM, DTS and Dolby TrueHD audio. Quickly connect HDMI cables (not included) and the power supply to complete this cost-effective 4K solution - no software or hardware configuration or complicated settings required.
- Replicates an Ultra-High-Definition (UHD) digital audio/video signal for up to four UHD HDMI displays
- [email protected] resolution, full 3D video and Deep Color
- Supports video amplifier bandwidth up to 340 MHz and 3.4 Gbps per channel (10.2 Gbps total) for 4Kx2K displays
- Supports 36-bit Deep Color (12-bits per channel) and sYCC Color Space
- Supports compressed DTS-HD Master Audio, 7.1 surround sound, Dolby TrueHD and uncompressed LPCM 8 channel audio
- HDCP compliant
- Multiple splitters (five total) may be cascaded up to support 16 4K displays
- Works with PlayStation and Xbox game systems, Blu-ray players, set-top boxes, satellite receivers and more
- Plug and play
- Gold-plated contacts for corrosion-free connections
- Three-year warranty
General Information
Name : Manhattan 207706 4k Compact 4-Port HDMI Splitter , Manhattan
Category : Pro HDMI Splitters
UPC Code : 766623207706
Country of Origin : . Country of origin is subject to change.
Specifications
General Information
ADI Part Number : 42-207706
Brand Name : Manhattan
Manufacturer : IC INTRACOM
Manufacturer Part Number : 207706
Product Name : 4K Compact 4-Port HDMI Splitter
Product Type : Signal Splitter
Weight (Approximate) (g) : 300
Technical Information
Connector Plating : Gold
Display & Graphics
Maximum Video Resolution : 4096 x 2160
Interfaces/Ports
HDMI In : Yes
HDMI Out : Yes
Number of HDMI Inputs : 1
Number of HDMI Outputs : 4
Physical Characteristics
Height : 0.7"
Height (mm) : 18
Material : Plastic
Package Type : Retail
Weight (Approximate) : 10.58 oz
Width : 2.3"
Width (mm) : 58
Power Description
Input Voltage : 5 V DC
Input Voltage (V DC) : 5
Product Information
Length : 3.2"
Length (mm) : 81
Warranty
Limited Warranty : 3 Year
Miscellaneous
Environmental Certification : RoHS 2
Environmentally Friendly : Yes
Package Contents : <ul> <li>4K Compact 4-Port HDMI Splitter</li> <li>Power Adapter</li> <li>Quick Instruction Guide</li> </ul>
