Digital Watchdog DW-VA1G482T VMAX A1 G4 8-Channel Analog DVR, 4K, 2TB (Replaces DW-VA1P81T)
DW-VA1G482T
|6K-VA1G482T
Shop all Digital Watchdog
Digital Watchdog DW-VA1G482T VMAX A1 G4 8-Channel Analog DVR, 4K, 2TB (Replaces DW-VA1P81T)
DW-VA1G482T | 6K-VA1G482T
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
VMAX A1 G4 is an embedded DVR that records standard analog, HD-Analog and HD-TVI formats at up to 4K resolution and 4K local video output. The DVR is a seamless upgrade to HD resolution for new ROI from existing coaxial infrastructure. Up the Coax (UTC) remote configuration is available with all compatible cameras. The 8-channel VMAX A1 G4 model is NDAA and TAA compliant and is available with up to 32TB of storage.
Main Features
- Universal HD over Coax DVR records HD-Analog, HD-TVI and standard coax up to 4K resolution
- PathFinder easy end-to-end remote connection with NAT Traversal (STUN/TUN) support
- Up the Coax (UTC) Communications Get off the ladder! Make adjustments toyour cameras from the DVR
- Camera Group Recording - Designate a group of cameras torespond to an alert from one camera
- Channel Swap - Swap a camera’s channelassignment without changingthe cable connections
- System Monitoring - A real-time graphicalrepresentation of all systemconnections Receive connectionalerts via email or text
- Thumbnail Search- Find video fast by clicking onthumbnails by the date, hourand minute
- NDAA / TAA Compliant
- C3 CMS - Central Monitoring Software for Windows and Mac
- Mobile Application for iOS and Android devices
General Information
Name: Digital Watchdog DW-VA1G482T VMAX A1 G4 8-Channel Analog DVR, 4K, 2TB (Replaces DW-VA1P81T)
Category: Digital Watchdog, Video Surveillance, Recording Devices & Servers, Video Surveillance DVRs, ADI Pro Rewards
UPC Code: 813379019562
Country of Origin: Korea. Country of origin is subject to change.
Specifications
ADI Part Number 6K-VA1G482T Brand Name Digital Watchdog Manufacturer Digital Watchdog Manufacturer Part Number DW-VA1G482T Maximum Supported Storage Capacity 2TB Minimum Storage Drive Space 2TB Product Line VMAX A1 G4 Product Model DW-VA1G482T Product Name Universal HD over Coax Digital Video Recorder Product Type Video Surveillance Station
Connectivity Technology Wired Maximum Frame Rate 240fps Number of Channels 8 Protocols DHCP, RTSP, Static fixed IP, UPnP Storage Capacity 2TB Video Formats H.264, MJPEG
Audio Encoding ADPCM Recording Modes Continuous, Emergency, Motion detection, Pre and post alarm, Quick backup, Scheduled, Sensor
TAA Compliant Yes
Maximum Video Resolution 3840 x 2160
Operating Humidity 0-80% RH Operating Temperature (T-T) 41-104°F
Number of Audio Line In 8 Number of Audio Line Out 1 Number of Ethernet Ports 1 Number of USB Ports 1 Output Ports CVBS, VGA Serial Port Yes
Ethernet Yes Ethernet Technology 1 Gigabit Ethernet Remote Management Yes
ADI Part Number Replaces 6K-DWVF81T, 6K-DWVF8500G, 6K-VA1P81T, 6K-VA1P82T, 6K-VAC81T, 6K-VAONE82T Model Number Replaces DW-VA1P81T, DW-VA1P82T, DW-VAC81T, DW-VAONE82T, DW-VF81T, DW-VF8500G
Depth 10.6" Dimensions 1.77" x 14.96" x 10.58", 12.4" x 9.52" x 1.77" Height 1.8" Width 15"
Maximum Power Consumption 48W
Hard Drive Capacity 2TB Number of Hard Drives Supported 2
Limited Warranty 5-Year
Certifications CE, FCC, NDAA, TAA Certifications & Standards CE, FCC, KC, NDAA, TAA Country of Origin KR Environmental Certification RoHS, WEEE Environmentally Friendly Yes Operating System Compatibility Linux Package Contents Mouse
