Overview
Specifications
Documents
Product Overview
Introducing the Altronix MAXFIT16A4 Power Supply, a versatile solution for your access control needs. This innovative device transforms a single 12 to 24V AC or DC input into four independently managed, fuse-protected outputs. Each output can be activated by various triggers, making it compatible with a range of access control hardware, including mag locks and electric strikes. Designed for flexibility, it can operate with one common power source or two separate ones. The FACP Interface allows for emergency egress and alarm monitoring, ensuring safety and reliability. Upgrade your security system today with the Altronix MAXFIT16A4 and experience peace of mind!
Main Features
- 19-Gauge steel enclosure
- Ample knockouts accommodating either 3/4" or 1" conduits for convenient access
- Cam lock and keys are included
General Information
Name: Altronix MAXFIT16A4 Power Supply, 12V/24V at 4A/Acm4/Bc750
Category: Altronix, Batteries & Power Supplies, Power Supplies & Boards, Power Supplies
UPC Code: 782239965281
Country of Origin: United States. Country of origin is subject to change.
Specifications
ADI Part Number AX-MFIT16A4 Brand Name Altronix Manufacturer Altronix Corporation Manufacturer Part Number MAXFIT16A4 Product Line MaxFit Product Model MAXFIT16A4 Product Name Altronix MAXFIT16A4 16 Channel 4A 12VDC or 4A 24VDC Access Control Power Supply Product Series MaxFit Product Type Power Supply Sector Access Control Weight 19.4lb
Number of Doors 16 Output Voltage 12V DC, 24V DC
NDAA Compliant Yes
Depth 6.25" Height 20.5" Width 16.5"
Input Voltage 120V AC
Country of Origin US Environmental Certification UL
