Product Overview
Introducing the Altronix TANGO8AP Access Power Controller, a versatile PoE-driven power supply and charger. This innovative device transforms an IEEE802.3bt PoE input into eight regulated outputs of 24VDC and/or 12VDC, along with eight protected outputs, delivering up to 65W of power. Say goodbye to high voltage concerns within enclosures! The TANGO8AP is specifically engineered to accommodate a single 12VDC LiFePO4 battery, ensuring reliable backup for both 12VDC and 24VDC applications. Enhance your power management solutions today with the Altronix TANGO8AP – your reliable partner in efficient power distribution!
Main Features
- PoE driven multi-output power supply
- Converts IEEE802.3bt PoE to 8 regulated outputs
- Provides 24VDC and/or 12VDC outputs
- Supports up to 65W power output
- Eliminates need for high voltage in enclosure
- Supports 12VDC LiFePO4 battery for backup
- PDS8 module with 12VDC and 24VDC inputs, 20A max output
- ACMS8 Controller with 8 trigger inputs and 20A max output
- Fire alarm disconnect with supervised latching options
- Operating temperature from 0°C to 49°C (32°F to 120°F)
General Information
Name: Altronix TANGO8AP Access Power Controller
Category: Altronix, Batteries & Power Supplies, Power Supplies & Boards, Access Power Controllers
UPC Code: 782239959716
Country of Origin: United States. Country of origin is subject to change.
Specifications
ADI Part Number AX-TANGO8AP Brand Name Altronix Manufacturer Part Number TANGO8AP Product Line Tango Product Model TANGO8AP Product Name PoE Driven Multi-Output Power Supply/Charger With Access Power Controller, BC400 Enclosure Product Series Tango Product Type Power Supply Sector Access Control Weight 9.3lb
Number of Doors 8 Output Voltage 12V DC, 24V DC
NDAA Compliant Yes
Operating Temperature (T-T) 32-120°F Storage Temperature (T-T) -4-158°F
Depth 4.5" Height 15.5" Width 12"
Input Voltage 48-57V
Country of Origin US Indoor/Outdoor Indoor
