Fire-Lite SD365-IV Addressable Photoelectric Smoke Detector, LiteSpeed and CLIP, (Replaces SD355)
SD365-IV
|FL-SD365IV
Shop all Fire-Lite Alarms by Honeywell
Fire-Lite SD365-IV Addressable Photoelectric Smoke Detector, LiteSpeed and CLIP, (Replaces SD355)
SD365-IV | FL-SD365IV
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Models SD365 and SD365-IV are plug-in type smoke sensors that combine a photoelectronic sensing chamber with addressable-analog communications. The sensors transmit an analog representation of smoke density over a communication line to a control panel. Rotary dial switches are provided for setting the sensor’s address. SD365-IV will support either LiteSpeed or CLIP (Classic Loop Interface Protocol) mode. The possible features available if supported by the control panel are: 1. The sensor’s LEDs can operate in three ways—on, off, and blinking–and they can be set to red, green, or amber. This is controlled by the panel. 2. The remote output may be synchronized to the LED operation or controlled independent of the LEDs. 3. Devices are point addressable up to 159 addresses.
Main Features
- New modern profile
- Analog communications
- Low standby current
- Rotary address switches
- Dual LEDs for 360° visibility
- Expanded color options including white, ivory and black (color kit)
- Includes 6" mounting base and trim ring
General Information
Name: Fire-Lite SD365-IV Addressable Photoelectric Smoke Detector, LiteSpeed and CLIP, (Replaces SD355)
Category: Fire-Lite Alarms by Honeywell, Fire, Fire Detection Devices & Accessories, Smoke Detectors
UPC Code: 783863051753
Country of Origin: Mexico. Country of origin is subject to change.
Specifications
ADI Part Number FL-SD365IV Brand Name Fire-Lite Alarms by Honeywell Manufacturer Honeywell International, Inc Manufacturer Part Number SD365-IV Product Model SD365-IV Product Name SD365-IV Smoke Detector Product Series SD365 Product Type Smoke Detector
Addressable Yes Application/Usage Residential Connectivity Technology Wired Detectable Medium Fire Sensing Technology Photoelectric Sensor Type Photoelectric
UL Listed Yes
Status Indicators Yes
ADI Part Number Replaces FL-SD355 Model Number Replaces SD355
Color White Form Factor Ceiling Mount Height 2" Weight 3.40oz Width 2"
Input Voltage 32V DC Power Source DC
Diameter 6.2" Mount Type Ceiling Mount
Certifications UL 268, UL 268A Country of Origin MX Features Models SD365 and SD365-IV are plug-in type smoke sensors that combine a photoelectronic sensing chamber with addressable-analog communications, The sensors transmit an analog representation of smoke density over a communication line to a control panel. Rotary dial switches are provided for setting the sensor�s address
