The GRI 180 Series is the industry standard 3/4" diameter recessed steel door switch set with 12" leads. The 184 Series is a 1" diameter switch set.
The innovative GRI 8080-T Series is a 3/4" diameter recessed switch set designed for residential, commercial and industrial steel doors and frames. The shorter length and the introduction of PC board type terminals makes the installation of the set quick and simple with no soldering, B connectors or tape to catch during installation or removal, reducing the cost of installation and creating greater profitability.
- Lifetime Warranty
- Colors: White, Brown, Grey or Black
- UL and ULC Approved
- 180-12 & 184-12 UL 10C Fire Rated
- Available in Closed Loop, Open Loop and SPDT
- 3/4" and 1" Diameter Mounting
- Standard 12" Leads or Terminals
- Solid, One Piece Design
- 7/8" Diameter also Available - Call Factory
- Switches or Magnets are Available Separately
- Standard 1/2"+ Gap on Steel
- Wide Gap 1"+ Gap on Steel
- Supervisory Loops Available
Name : GRI 185-12WG-W 3/4" Steel Door Recessed Switch Set, Wide Gap, 5W, 175VDC, 0.25 Amp, Open Loop, N/C, B, White , George Risk Industries
Category : Magnetic Contacts
UPC Code : 697625024667
Country of Origin : United States. Country of origin is subject to change.
ADI Part Number : GI-18512WG
Brand Name : GRI
Manufacturer : George Risk Industries
Manufacturer Part Number : 185-12WG-W
Product Model : 185-12WG-W
Product Name : 185-12WG-W Magnetic Contact
Product Type : Magnetic Contact
Contact Configuration : N.C.
Contact Form : Form B
Contact Resistance : 140000 Micro Ohm
Contact Resistance (Ohm) : 0.14
Lead Length : 12"
Lead Length (mm) : 304.8
Mounting Type : Recessed Mount
Recommended Use : Door
Standard Gap : 0.75"
Standard Gap (mm) : 19.05
Connectivity Technology : Cable
Application/Usage : Commercial, Industrial, Residential
Color : White
Diameter (mm) : 19.05
Contact Type : Open Loop
Diameter : 0.8"
Limited Warranty : Lifetime
Additional Information : <ul> <li>Switches or Magnets are Available Separately</li> <li>Wide Gap 1"+ Gap on Steel</li> <li>Supervisory Loops Available</li> <li>Longer Leads, Zip Cord or Jacketed Cable Upon Request</li> </ul>
Certifications & Standards : <ul> <li>UL</li> <li>ULC</li> <li>UL 10C</li> </ul> <p></p>
Country of Origin : United States
Features : End of Line (EOL) Resistor, Self-lock Mounting
