GRI 29A-G W/2K 29 Series Surface Mount Magnetic Reed Switch Set with 2K Resistor, 1" Standard Gap, 10W, 160VDC, 0.40A, Closed Loop, N/O, Side Mounted Screw Terminals, Gray
29A-G W/2K
|GI-29AGW2K
Shop all George Risk Industries
GRI 29A-G W/2K 29 Series Surface Mount Magnetic Reed Switch Set with 2K Resistor, 1" Standard Gap, 10W, 160VDC, 0.40A, Closed Loop, N/O, Side Mounted Screw Terminals, Gray
29A-G W/2K | GI-29AGW2K
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
This series offers a standard gap of 1 inch, a wide gap of up to 1 1/2 inches and an extra wide gap of 2 inches and can be installed on a steel surface with a minimum gap penalty. The “P” style is a pre-wired switch with 2 feet of conductor cable. A broad range of mounting brackets are also available.
Main Features
- 24" jacketed cable on PA Series
- Longer leads upon request on PA series
- Side mounted screw terminals on 29 series
- Standard gap up to 1", 5/8" on steel
- Wide gap up to 1 1/2", 3/4" on steel
- Extra wide gap up to 2", 1" on steel
- Spacers, covers and screws Included
General Information
Name: GRI 29A-G W/2K 29 Series Surface Mount Magnetic Reed Switch Set with 2K Resistor, 1" Standard Gap, 10W, 160VDC, 0.40A, Closed Loop, N/O, Side Mounted Screw Terminals, Gray
Category: George Risk Industries, Intrusion, Alarm Contacts, Magnetic Contacts
UPC Code: 697625042746
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number GI-29AGW2K Brand Name George Risk Industries Manufacturer Part Number 29A-G W/2K
Color Gray
