GRI 50F-12WG-B-BA 1 1/2" Miniature Surface Mount Switch Set, Wide Gap 3/4”+, Closed Loop, A Reed Form, 10W, Breakaway Flanges, Brown
Brand: George Risk Industries
ADI #:GI-50F12WGB
Model #: 50F-12WG-B-BA
Name: GRI 50F-12WG-B-BA 1 1/2" Miniature Surface Mount Switch Set, Wide Gap 3/4”+, Closed Loop, A Reed Form, 10W, Breakaway Flanges, Brown
- The GRI 50F Series switch sets are the most chosen configurations for residential installations. A low profile plus self-adhesive 3M tape make installing the sets quick and simple.
- The 50F comes with a breakaway flange for applications where screw mounts are advisable.
Product Overview
The GRI 50, 50F and 55F Series switch sets are the most chosen configurations for residential installations. A low profile plus self adhesive 3M tape make installing the sets quick and simple. The 50F and 55F come with a breakaway flange for applications where screw mounts are advisable. The 50 type is self adhesive only. The 50 and 50F have 12" leads exiting the case on the end. The 55F has 12" leads exiting from the middle of the case.
Available in Open Loop, Closed Loop and SPDT, Regular and Wide Gap, White, Brown and Gray. All mounting hardware included.
INSTALLATION APPLICATIONS:
The G.R.I. 50, 50F and 55F series switch sets are the most chosen configurations for residential installations. Low profile and self adhesive 3M tape make installing the sets quick and simple. The 50F and 55F come with a breakaway flange for applications where screw mounts are advisable. The 50 type is self adhesive only. The 50 and 50F have 12" leads exiting the case on the end. The 55F has 12" leads exiting from the middle of the case. Available in open loop, closed loop and SPDT, regular and wide gap, White, Brown, Gray and Almond . All mounting hardware included.
Available in Open Loop, Closed Loop and SPDT, Regular and Wide Gap, White, Brown and Gray. All mounting hardware included.
INSTALLATION APPLICATIONS:
The G.R.I. 50, 50F and 55F series switch sets are the most chosen configurations for residential installations. Low profile and self adhesive 3M tape make installing the sets quick and simple. The 50F and 55F come with a breakaway flange for applications where screw mounts are advisable. The 50 type is self adhesive only. The 50 and 50F have 12" leads exiting the case on the end. The 55F has 12" leads exiting from the middle of the case. Available in open loop, closed loop and SPDT, regular and wide gap, White, Brown, Gray and Almond . All mounting hardware included.
General Information
Name : GRI 50F-12WG-B-BA 1 1/2" Miniature Surface Mount Switch Set, Wide Gap 3/4”+, Closed Loop, A Reed Form, 10W, Breakaway Flanges, Brown , George Risk IndustriesCategory : Magnetic Contacts
UPC Code : 697625009398
Country of Origin : United States. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : GI-50F12WGB
Brand Name : GRI
Manufacturer : George Risk Industries
Manufacturer Part Number : 50F-12WG-B-BA
Product Model : 50F-12WG-B-BA
Product Name : 50F-12WG-B-BA Magnetic Contact
Product Series : 50F
Product Type : Magnetic Contact
Technical Information
Contact Configuration : N.O.
Contact Form : Form A
Contact Resistance : 150000 Micro Ohm
Contact Resistance (Ohm) : 0.15
Lead Length : 12"
Lead Length (mm) : 304.8
Mounting Type : Surface Mount
Standard Gap : 0.75"
Standard Gap (mm) : 19.05
Termination Style : Side Lead
Camera
Connectivity Technology : Cable
Physical Characteristics
Application/Usage : Industrial
Color : Brown
Product Information
Contact Type : Closed Loop
Warranty
Limited Warranty : Lifetime
Miscellaneous
Additional Information : <ul> <li>Excellent For Residential Applications</li> <li>Hermetically Sealed</li> <li>Plated Contacts Resist Sticking or Freezing</li> <li>Mounting Hardware Included</li> <li>Supervisory Loops Upon Request</li> </ul>
Certifications & Standards : <ul> <li>UL</li> <li>ULC</li> </ul> <p></p>
Country of Origin : United States
Features : End of Line (EOL) Resistor
Package Contents : <ul> <li>50F-12WG-B-BA Magnetic Contact</li> <li>Mounting Hardware</li> </ul>
