On-Q PT8300-BL Hospital Grade Extra Heavy Duty Duplex Receptacle, 20A/125V, Blue
PT8300-BL|H4-PT8300BL
On-Q PT8300-BL Hospital Grade Extra Heavy Duty Duplex Receptacle, 20A/125V, Blue
PT8300-BL|H4-PT8300BL
Key Features
- 0.036 inch thick, brass, triple-wipe power contacts for lasting retention
- Large brass contacts snugly terminate on device blade terminals
- No exposed terminals create a finger safe application before, during, and after installation
Key Features
- 0.036 inch thick, brass, triple-wipe power contacts for lasting retention
- Large brass contacts snugly terminate on device blade terminals
- No exposed terminals create a finger safe application before, during, and after installation
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- 0.036 inch thick, brass, triple-wipe power contacts for lasting retention
- Large brass contacts snugly terminate on device blade terminals
- No exposed terminals create a finger safe application before, during, and after installation
On-Q by Legrand
On-Q PT8300-BL Hospital Grade Extra Heavy Duty Duplex Receptacle, 20A/125V, Blue
PT8300-BL | H4-PT8300BL
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
PlugTail Extra Heavy-Duty Hospital Grade Receptacles, 20A, 125V PlugTail devices and connectors mean that device installation is the same regardless of skill level of the installer. The UL-Listed connectors are keyed to ensure proper wiring installation into each receptacle.
Main Features
- 0.036 inch thick, brass, triple-wipe power contacts for lasting retention
- Large brass contacts snugly terminate on device blade terminals
- No exposed terminals create a finger safe application before, during, and after installation
- Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections
- Crimped and welded contacts
- Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing
- Pre-stripped connector leads fasten to conductors, easier than standard pigtails
- Auto-ground clip assures positive ground
- Temperature Rise; Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature; Maximum continuous 60°C, minimum -40°C without impact
General Information
Name: On-Q PT8300-BL Hospital Grade Extra Heavy Duty Duplex Receptacle, 20A/125V, Blue
Category: On-Q by Legrand, Batteries & Power Supplies, Electrical Plugs & Connectors, Single & Duplex Outlets
UPC Code: 785007091922
Country of Origin: . Country of origin is subject to change.
Specifications
-
ADI Part Number H4-PT8300BL Brand Name On-Q by Legrand Manufacturer Part Number PT8300-BL Product Name PlugTail 20A 125V Extra Heavy Duty Hospital-Grade Duplex Receptacle, Blue Product Type Duplex Receptacle
-
Color Blue Depth 0.625" Height 2.75" Width 1.5"
-
Current Rating 20A Voltage Rating 125V
-
Certifications & Standards cULus UL498 Country of Origin MX Environmental Certification UL94 V2
