Image of I2-IFP210ECS

Farenhyt IFP-2100ECS Intelligent Fire Alarm Control Panel with Emergency Communication System, Red Cabinet

IFP-2100ECS|I2-IFP210ECS

Farenhyt IFP-2100ECS Intelligent Fire Alarm Control Panel with Emergency Communication System, Red Cabinet

IFP-2100ECS|I2-IFP210ECS
Key Features
  • Single enclosure for both Fire and Emergency Control system components
  • Can select ECS message as priority over fire
  • Network support for up to 32 Sites
Key Features
  • Single enclosure for both Fire and Emergency Control system components
  • Can select ECS message as priority over fire
  • Network support for up to 32 Sites

Sign In for Dealer Pricing

Become an ADI Customer
Key Features
  • Single enclosure for both Fire and Emergency Control system components
  • Can select ECS message as priority over fire
  • Network support for up to 32 Sites
Honeywell Farenhyt Series

Farenhyt IFP-2100ECS Intelligent Fire Alarm Control Panel with Emergency Communication System, Red Cabinet

IFP-2100ECS | I2-IFP210ECS

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The IFP-2100ECS (red) and IFP-2100ECSB (black) are intelligent analog/addressable Fire Alarm Control Panels combined with an Emergency Communication System (ECS). When the ECS features are enabled, they are integrated with the fire alarm and voice evacuation functions of the control panel. The IFP-2100ECS panel and accessories provide features to meet the requirements for Mass Notification Systems as described in UL 2572. This state of the art fire alarm control panel allows you to choose one of three SLC protocols per system. The IFP-2100ECS panel contains one built in signaling line circuit (SLC), which can support 159 System Sensor IDP/ SK sensors and 159 IDP/SK modules or 127 Hochiki SD devices per loop. Additional SLC loops can be added using the model 6815 SLC expander for IDP/SK devices or model 5815XL for SD devices to increase the overall point capacity to a maximum of 2100 points per panel.

Main Features

  • Single enclosure for both Fire and Emergency Control system components
  • Can select ECS message as priority over fire
  • Network support for up to 32 Sites
  • Available in a red or black cabinet
  • Separate network support for voice paging
  • Built-in USB interface for programming
  • Four programmable function keys
  • JumpStart, Auto Programming feature for easy programming
  • Capable of producing 520 Hz tones to meet NFPA 72 requirements
  • 15 Recordable one minute messages that can be mapped to eight ECS buttons

General Information

Name: Farenhyt IFP-2100ECS Intelligent Fire Alarm Control Panel with Emergency Communication System, Red Cabinet
Category: Honeywell Farenhyt Series, Fire, Fire Control Panels, Fire Alarm Control Panels
UPC Code: 783196014289
Country of Origin: United States. Country of origin is subject to change.
