LifeSafety Power FPO150-B100C8D8E4A/T8-C 150W Dual Voltage Power Supply, 8 Lock Outputs, 8 Auxiliary Outputs, E4A
FPO150-B100C8D8E4A / T8-C
|J7-15BCD4ATC
Shop All LifeSafety Power
LifeSafety Power FPO150-B100C8D8E4A/T8-C 150W Dual Voltage Power Supply, 8 Lock Outputs, 8 Auxiliary Outputs, E4A
FPO150-B100C8D8E4A / T8-C | J7-15BCD4ATC
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
These ProWire Unified Power wall mount models are single and dual voltage access power systems, precision wired for AMAG controllers. ProWire enables the specification and installation of standardized access power equipment across an enterprise for uniform operation, maintenance and servicing.The C8 or M8 control modules provide eight access control inputs capable of voltage or dry contact activation, and eight outputs programmable for failsafe/failsecure operation at either 12 or 24 V DC and controlled by the power supply fire alarm interface. The D8 module provides eight auxiliary outputs. In these dual voltage systems each output is configurable for 12 or 24V DC operation.
Specifications
ADI Part Number J7-15BCD4ATC Brand Name LifeSafety Power Manufacturer Part Number FPO150-B100C8D8E4A / T8-C Sector Access Control
Output Voltage 12, 24V DC
Depth 6.5" Height 24" Width 20"
Input Voltage 120, 230V AC
Environmental Certification CSA C22.2 107.1, CSFM, FCC Part 15, UL294, ULC S319
