LifeSafety Power FPV6-R8PE1 Video Power System, 8 Auxiliary, 1 Managed Output, Rackmount Enclosure, Gray

FPV6-R8PE1 | J7-FPV6RPE1

Please sign in to view pricing, availability, and to add to cart.

Overview

Specifications

Documents

Product Overview

LifeSafety Power's FPV6-R8PE1 is a power supply and control module designed for 6A 12V or 24V applications with capacity to support up to 8 locks. It features outputs that are individually selectable as latching or non-latching and supports various configurations including normally open, normally closed, open collector sink, and positive or negative voltage application. The module incorporates essential protections such as NAC loop, short circuit, thermal overload, reverse battery protection, and low power cutoff to prevent battery deep discharge. Additionally, it includes a built-in 1.5A fast charger, autoswitch functionality to battery with zero voltage drop, and status indications with green, red, and bi-color LEDs for AC input, DC output, fault alerts, relay activity, and output voltage level.

Main Features

Latching or non-latching, is individually selectable for each output
Normally open, normally closed, open collector sink, positive or negative voltage application, NAC loop, short circuit and thermal overload protection
Built in fast charger at 1.5A current
Autoswitch to battery with zero voltage drop
Low power cutoff to prevent battery deep discharge
Reverse battery protection
FPV - Green LEDs for AC input and DC output status. Red LED shows FAI triggered
R8 - Red LED relay active. OutSmart BiColor LED shows output Voltage (Green/12V, Blue/24V)

General Information

Name: LifeSafety Power FPV6-R8PE1 Video Power System, 8 Auxiliary, 1 Managed Output, Rackmount Enclosure, Gray

Category: LifeSafety Power, Batteries & Power Supplies, Power Supplies & Boards, Power Supply Boards, Power Supplies

UPC Code: 810004919907

Country of Origin: United States. Country of origin is subject to change.

Specifications

: ADI Part Number J7-FPV6RPE1 Brand Name LifeSafety Power Manufacturer Part Number FPV6-R8PE1

: Depth 4.5" Height 14" Width 12"

: Input Voltage 120V AC Output Power 160W

: Limited Warranty Lifetime Warranty

: Environmental Certification BIS IS13252(Part 1):2010, CSA C22.2 107.1, CSFM IEC 62368-1:2014, EN 55032:2015, EN55024:2010+A1:2015, EN6100-3-2:2014, EN6100-3-3:2013, FCC Part 15, NOM-001-SCFI-1933, RCM AS/NZS 4417.1, REACH 209, RoHS 3, SAA AS/NZS 62368.1:2018, Subpart B, UL1076, UL294, ULC S318, ULC S319
