LifeSafety Power RGM75-C8D8PZ/T4-C Rugged Power System, 8 Lock, 8 Auxiliary Outputs, Tie-Wrap Wiring, Zinc-Coated Steel Enclosure, Gray
RGM75-C8D8PZ/T4-C|J7-RG75CDTC
LifeSafety Power RGM75-C8D8PZ/T4-C Rugged Power System, 8 Lock, 8 Auxiliary Outputs, Tie-Wrap Wiring, Zinc-Coated Steel Enclosure, Gray
RGM75-C8D8PZ/T4-C|J7-RG75CDTC
Key Features
- Guarantees uniform installations across an enterprise
- Pre-installed wire harness for panel power, lock control, faults and tamper switch
- Point to point wiring labeled, color coded, twisted pair, shielded communication
Key Features
- Guarantees uniform installations across an enterprise
- Pre-installed wire harness for panel power, lock control, faults and tamper switch
- Point to point wiring labeled, color coded, twisted pair, shielded communication
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- Guarantees uniform installations across an enterprise
- Pre-installed wire harness for panel power, lock control, faults and tamper switch
- Point to point wiring labeled, color coded, twisted pair, shielded communication

LifeSafety Power
LifeSafety Power RGM75-C8D8PZ/T4-C Rugged Power System, 8 Lock, 8 Auxiliary Outputs, Tie-Wrap Wiring, Zinc-Coated Steel Enclosure, Gray
RGM75-C8D8PZ/T4-C | J7-RG75CDTC
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
These ProWire Unified Power rack mount models are single and dual voltage access power systems, precision wired for Mercury controllers. ProWire enables the specification and installation of standardized access power equipment across an enterprise for uniform operation, maintenance and servicing.
Main Features
- Guarantees uniform installations across an enterprise
- Pre-installed wire harness for panel power, lock control, faults and tamper switch
- Point to point wiring labeled, color coded, twisted pair, shielded communication
- Tie wrap cable management
- Managed systems monitor power, batteries and eight outputs
- UL294, ULC S319 joint LSP / Mercury integrated listing
General Information
Name: LifeSafety Power RGM75-C8D8PZ/T4-C Rugged Power System, 8 Lock, 8 Auxiliary Outputs, Tie-Wrap Wiring, Zinc-Coated Steel Enclosure, Gray
Category: LifeSafety Power, Batteries & Power Supplies, Power Supplies & Boards, Power Supplies
UPC Code: 8100049110943
Country of Origin: United States. Country of origin is subject to change.
Specifications
-
ADI Part Number J7-RG75CDTC Brand Name LifeSafety Power Manufacturer Part Number RGM75-C8D8PZ/T4-C
-
Output Voltage 12, 24V DC
-
Depth 20.5" Height 3.5" Width 19"
-
Input Voltage 120, 230V AC
-
Environmental Certification CSA C22.2 107.1, CSFM, EN55024:2010 +A1:2015, EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, FCC Part 15, IEC 62368-1:2014, India BIS IS13252(Part1):2010, Mexico NOM 001:2018, UL1076, UL294, ULC S319
