Product Overview
Compact, easy-to-deploy 2K HD PoE camera that can be staged indoors or outside.
General Information
Name : Ubiquiti UVC-G5-FLEX G5 Flex IR 4MP 2K HD PoE IP Camera, Table or Ceiling Mount , Ubiquiti
Category : Bullet Cameras
UPC Code : 810084690222
Country of Origin : +1. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : KX-UVCG5FLEX
Brand Name : Ubiquiti
Manufacturer : Ubiquiti Inc.
Manufacturer Part Number : UVC-G5-FLEX
Product Line : UVC
Product Model : UVC-G5-FLEX
Product Name : Ubiquiti Networks UniFi UVC-G5-FLEX 4MP Network Camera with Night Vision
Product Series : G5
Product Type : Network Camera
Weight (Approximate) (g) : 170
Technical Information
Connectivity Technology : Wired
Effective Camera Resolution : 5MP
Field of View : H: 102.4°/V: 54.9°/D: 120.6°
HD Recording : Yes
Lens Type : Fixed
Maximum Frame Rate : 30 fps
Night Vision : Yes
Night Vision Type : Infrared
Power Consumption (PoE) (W) : 4
Audio
Shipping Weight (Approximate) (g) : 342.462
Camera
Night Vision Distance : 20 ft
Night Vision Distance (mm) : 6096
Display & Graphics
Color Supported : Color
Effective Camera Resolution (Pixel) : 5000000
Maximum Video Resolution : 2688 x 1512
Environmental Conditions
Maximum Operating Temperature : 104°F
Maximum Operating Temperature (°F) : 104
Minimum Operating Temperature : -4°F
Minimum Operating Temperature (°F) : -4
Operating Humidity : 0-90%
Interfaces/Ports
Network (RJ-45) : Yes
Network & Communication
Remote Management : Yes
Physical Characteristics
Diameter (mm) : 48
Durability : Weather Proof, Weather Resistant
Form Factor : Ceiling Mount, Desktop Mount, Pole Mount, Wall Mount
Height : 4.2"
Height (mm) : 107.5
Weight (Approximate) : 6 oz
Power Description
Input Voltage : 37 V DC, 57 V DC
Product Information
Diameter : 1.9"
Mount Type : Ceiling Mount, Desktop Mount, Pole Mount, Wall Mount
Video
Maximum Frame Rate (fps) : 30
Warranty
Limited Warranty : 1 Year
Miscellaneous
Environmental Certification : IPX4
Features : 2K (4MP) video resolution, 6 m (20 ft) IR night vision, AI event detections, Connect and power using PoE, Record audio with an integrated microphone, Versatile table or ceiling mounting, Weather-resistant (outdoor covered)
Impact Protection Rating : IK04
Indoor/Outdoor : Outdoor
Ingress Protection Rating : IPX4
Package Contents : <ul><li> G5 Flex Network Camera</li><li> Desktop Mount</li><li> Wall Mount</li><li> Pole Mount</li><li> Hard-ceiling Mount</li></ul>
