LEA Professional CONNECT 164D 4-Channel Amplifiers with Dante, 160W per Channel
164D | LD-CNNCT164D
Please sign in to view pricing and availability and to add to cart.
Accessories
Product Overview
The CONNECTSERIES 164D is a 4-channel amplifier with 160 watts per channel. As part of the Dante CONNECTSERIES, the world's first Internet of Things- (IoT) enabled professional-grade amplifiers, it is perfectly suited for small to medium-scale installations. The 164D features direct HiZ (70V or 100V) or LoZ selectable by channel. With three ways to connect, you can engage the built-in Wi-Fi access point, connect to the venue's Wi-Fi, or use the FAST Ethernet to connect to any local area network via Cat5 or Cat6 cable.
Then there's the Cloud...DANTE CONNECTSERIES is the first professional amplifier family to feature Cloud connectivity. Harness the power of the Cloud for remote control, monitoring, notifications, and more from any of your personal devices. Just connect your amp to a network and start commanding your systems. Register for your free LEA Cloud account at leaprofessional.cloud
The DANTE CONNECTSERIES also features analog inputs and Dante inputs and external I/O control for remote on/off and fault monitoring.
Main Features
- Analog fully routable inputs
- Direct LoZ and HiZ (70V or 100V) selectable per channel
- External I/O port for remote on/off and fault monitoring
- Highly efficient Class D output stage for low AC current draw
- Web browser-based UI – works on any device with no software to download
- Universal switch mode power supply with PFC: operation from 100VAC – 240VAC +/-15%
- CONNECT 164 uses 80 watts per channel with 2, 4, 8 Ohms, and 70V / 100V use 160 watts per channel
- 3 ways to connect: built in WiFi access point, existing WiFi network, Local Area Network Ethernet connection
- Proprietary Smart Power Bridge allows user to bridge a channel to achieve double the power of that channel without sacrificing an amplifier channel
- 96kHz analog devices DSP with input routing, multiple 48dB/Oct crossover filters, 8 parametric EQ filters, user configurable speaker limiters, and real time load monitoring
General Information
Specifications
-
ADI Part Number LD-CNNCT164D Brand Name LEA Professional Manufacturer LEA Professional Manufacturer Part Number CONNECT 164D Product Line Connect Product Model 164D Product Name Connect 164D Amplifier Product Type Amplifier Weight 12.25lb
-
Audio Channels 4 Classification D Impedance 8 ohms
-
Maximum Frequency Response 20 kHz Minimum Frequency Response 20 Hz RMS Output Power 160W Total Harmonic Distortion (THD) 0.1%
-
Energy Star No TAA Compliant Yes
-
Operating Power Consumption 150W
-
Ethernet Yes
-
Form Factor Rack Mount Width 19"
-
Input Voltage 120V AC, 230V AC
-
Length 14.2"
-
Limited Warranty 6-Year
-
Country of Origin CR Environmental Certification RoHS Features DC Offset Protection, Digital Signal Processing Indoor/Outdoor Indoor
