Leviton 18D29-UW Female Detachable Plug, Ball Nose, 1-Set Screw, 2-2/0AWG, White
18D29-UW
|LV-18D29UW
Shop all Leviton
Leviton 18D29-UW Female Detachable Plug, Ball Nose, 1-Set Screw, 2-2/0AWG, White
18D29-UW | LV-18D29UW
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
18 Series Cam-Type Female Detachable Plug, Single Set Screw Termination, Ball Nose, #2 – 2/0 AWG, 300 Amp Max, White Leviton’s Rhino-Hide Single Pole Cam-Type Connectors supply temporary electrical power for both indoor and outdoor applications. These devices are designed for easy assembly and disassembly, without special tools. Single or double set screw termination NEMA 3R rated for outdoor use when mated UL; 1691, 508 – 35k A / 600V Short Circuit Current Rating Color-coding provides fast and easy phase identification Common applications; entertainment, oil and gas, mining operations, power distribution, construction sites, and other temporary power applications.
Main Features
- 18 Series Cam-Type Female Detachable Plug
- Single Set Screw Termination
- Ball Nose Design
- Supports #2 – 2/0 AWG
- 300 Amp Maximum Capacity
- White Color for Easy Identification
- Easy Assembly and Disassembly
- NEMA 3R Rated for Outdoor Use
- UL 1691, 508 Certified
- Ideal for Temporary Power Applications
General Information
Name: Leviton 18D29-UW Female Detachable Plug, Ball Nose, 1-Set Screw, 2-2/0AWG, White
Category: Leviton, Batteries & Power Supplies, Electrical Cords & Connectors, Power Plugs
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number LV-18D29UW Brand Name Leviton Manufacturer Part Number 18D29-UW Product Name Female Plug, #2 - 2/0 AWG, Single Set Screw Termination Product Type Connector
Connector Type Single Set Screw
Color White
Voltage Rating 600V
