Lantronix TN-10GSFP-LR4M-D35 SFP Module Transceiver SFP+ 1000BASE-LX/10GBASE-ER, 1G/1
TN-10GSFP-LR4M-D | P6-GFPLRM35
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
10G Base-ER/1000Base-LX, SFP+ with DMI single mode (LC) 1549.32nm 193.50THZ (40 km/24.9 mi.) Link Budget- 15.0 dB.
Main Features
- SFP+ Optical Transceiver with duplex LC connector
- 1G/10G Small Form-Factor Pluggable (SFP+) MSA compliant
- Compliant with 10GBase-ER/ZR
- Compliant with 1000Base-LX/ZX
- SFF-8472 Digital Diagnostic Function (DMI)
- SFF-8431 and SFF-8432 Compliant
- Maximum Link Length of 80KM
- Single +3.3 V Power Supply
- Lower power dissipation <1.5 Watts
- RoHS Compliant
General Information
Name: Lantronix TN-10GSFP-LR4M-D35 SFP Module Transceiver SFP+ 1000BASE-LX/10GBASE-ER, 1G/1
Category: Lantronix, Video Surveillance, Data Comm & Networking, Networking Devices, Media Converters & Transceivers, SFP Modules, SFP Modules
UPC Code: 783384252066
Country of Origin: . Country of origin is subject to change.
Specifications
-
ADI Part Number P6-GFPLRM35 Brand Name Lantronix Manufacturer Lantronix, Inc Manufacturer Part Number TN10GSFPLR4MD35 Product Model TN-10GSFP-LR4M-D Product Name TN-10GSFP-LRxM-Dxx SFP+ Module Product Series TN-10GSFP-LRxM-Dxx Product Type SFP+
-
Media Type Supported Optical Fiber
-
TAA Compliant Yes
-
Number of Ports 1
-
Network Technology 1000Base-LX, 10GBase-DWDM, 10GBase-ER
-
Ethernet Technology 10 Gigabit Ethernet
-
Depth 2.2" Form Factor Plug-in Module Height 0.3" Width 0.5"
-
Input Voltage 3.3V
-
Limited Warranty Lifetime
-
Compatibility MSA Compliant Country of Origin TW Environmental Certification REACH, RoHS, WEEE Environmentally Friendly Yes
