Lantronix M/E-PSW-FX-02-JP Mini 10/100BASE-TX to 100BASE-FX Switch, ST Multimode
M/E-PSW-FX-02
|P6-MEPWFX2JP
Shop all Lantronix
Lantronix M/E-PSW-FX-02-JP Mini 10/100BASE-TX to 100BASE-FX Switch, ST Multimode
M/E-PSW-FX-02 | P6-MEPWFX2JP
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Mini Fast Ethernet Media Converter
10/100Base-TX to 100Base-FX
The M/E-PSW Series is a Fast Ethernet stand-alone Mini media converter that provides cost effective media conversion between 10/100Base-TX ports and 100Base-FX ports. With its fixed configuration, deployments are just plug-and-play, and its small size makes it ideal for locations where space is limited. Operating at Layer 2, the data link layer, this converter not only converts copper to fiber, it also provides rate conversion allowing legacy 10Base-T copper devices to connect to 100Base-FX fiber.
Main Features
- Unit and Port LEDs allow for quick status information
- Auto-Negotiation
- Fixed Full-Duplex on fiber
- Auto-MDI/MDIX
- Automatic Link Restoration
- Far-End-Fault (FEF)
- Connect to legacy network equipment
- Eliminate Collision Domains
General Information
Name: Lantronix M/E-PSW-FX-02-JP Mini 10/100BASE-TX to 100BASE-FX Switch, ST Multimode
Category: Lantronix, Data Comm & Networking, Network Adapters, Media Converters
UPC Code: 648177047857
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number P6-MEPWFX2JP Brand Name Lantronix Manufacturer Lantronix, Inc Manufacturer Part Number MEPSWFX02JP Maximum Distance 1.24 Mile Packaged Quantity 3 Product Model M/E-PSW-FX-02 Product Name M/E-PSW-FX-02 Transceiver/Media Converter Product Series M/E-PSW Product Type Transceiver/Media Converter
Fiber Optic Mode Multimode Media Type Supported Optical Fiber, Twisted Pair Power Consumption 2.60W
TAA Compliant Yes
Network (RJ-45) Yes Number of Network (RJ-45) Ports 1 Number of Ports 2 Number of ST Ports 1
Fiber Optic Wavelength 1300 nm Network Technology 10/100Base-TX, 100Base-FX
Ethernet Technology 10 Gigabit Ethernet
Depth 3.3" Height 0.9" Weight 2lb Width 1.8"
Input Voltage 13.9V DC, 7.5V DC Power Source AC, DC
Limited Warranty Lifetime
Environmental Certification REACH, RoHS, WEEE Environmentally Friendly Yes Package Contents M/E-PSW-FX-02 Transceiver/Media ConverterDIN Rail Clip and VelcroPower Supply - Japan
