Lantronix SM24TAT4XB-JP 24-Port Managed Gigabit Ethernet PoE+ Switch with 4 1G/10G SFP+, 370W, Japan Power Cord
SM24TAT4XB-JP
|P6-SM24XBJP
Shop all Lantronix
Lantronix SM24TAT4XB-JP 24-Port Managed Gigabit Ethernet PoE+ Switch with 4 1G/10G SFP+, 370W, Japan Power Cord
SM24TAT4XB-JP | P6-SM24XBJP
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Managed Gigabit Ethernet PoE+ Switch
(24) 10/100/1000Base-T Ports + (4) 1G/10GBase-X SFP+ Ports
This switch is a high performance managed PoE+ switch with (24) 10/100/1000 copper ports and (4) dual speed 1G/10G SFP+ slots.
Main Features
- Supports Jumbo Frame up to 10240 bytes
- Authentication - RADIUS IEEE 802.1X, TACACS+
- Security - Support SSH/SSL
- Port based or tagged (IEEE 802.1Q) VLAN, MAC based VLAN,Management VLAN and Private VLAN Edge
- DHCP Server, Client, Relay
- IEEE 1588v2 PTP (TC)
- ACLs Support for up to 512 entries, drop or rate limitation based on source and destination MAC, VLAN ID or IP address, protocol, port, DSCP/IP precedence, TCP/IP source and destination ports, IEEE 802.1p priority, Ethernet Type / IGMP packets, TCP flag
- LLDP (Link Layer Discovery Protocol)
- IEEE 802.3az Energy Efficiency
General Information
Name: Lantronix SM24TAT4XB-JP 24-Port Managed Gigabit Ethernet PoE+ Switch with 4 1G/10G SFP+, 370W, Japan Power Cord
Category: Lantronix, Data Comm & Networking, Hubs, Routers & Switches, Network Switches
UPC Code: 783384250680
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number P6-SM24XBJP Brand Name Lantronix Manufacturer Lantronix, Inc Manufacturer Part Number SM24TAT4XBJP Product Model SM24TAT4XB-JP Product Name SM24TAT4XB Layer 3 Switch Product Series SM24TAT4XB Product Type Layer 3 Switch
Media Type Supported Optical Fiber, Twisted Pair Power Consumption 450W
TAA Compliant Yes
Expansion Slot Type SFP+ Number of Total Expansion Slots 4 Shared SFP Slot No
Modular Yes Network (RJ-45) Yes Total Number of Network Ports 24
Manageable Yes
Network Technology 10/100/1000Base-T, 10GBase-X
Ethernet Technology 10 Gigabit Ethernet Layer Supported 3 Networking Standards IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Depth 8.3" Height 1.7" Weight 8.38lb Width 17.4"
Input Voltage 120V AC, 230V AC PoE (RJ-45) Port Yes PoE Budget 370W Power Source AC, PoE+
Limited Warranty Lifetime
Environmental Certification REACH, RoHS, WEEE Environmentally Friendly Yes Package Contents SM24TAT4XB Layer 3 SwitchPower Cord Japan
