Product Overview
The Panduit SmartZone G5 iPDU is more than a power distribution unit and energy monitoring device. These iPDUs monitor the data center power and environment (at the rack or cabinet level), by continuously scanning for electrical circuit overloads, and physical environmental conditions that place critical IT equipment at risk. Panduit's iPDUs provide comprehensive, accurate, energy measurement data to efficiently use power resources, make informed capacity planning decisions, improve uptime, measure PUE (power usage effectiveness), and drive green data center initiatives to save energy and money.
Making the right choice in IT equipment is essential for a safe, efficient data center operation. Panduit's full range of iPDUs, environmental sensors, and dual locking power cords are the key to fulfilling mission-critical data center needs.
Main Features
- PDU provides active metering enabling energy optimization and circuit protection
- with monitored PDU, you can remotely monitor single-or three-phase voltage easily to ensure maximum power supply efficiency
- IEC 60320 C13/C15 receptacle type to ensure maximum productivity with added feasibility
- Three Phase phase PDU provides optimal power output with added usability
- NEMA L15-30P plug/connector type for better, dependable connectivity and desired power output
- 230 V AC input voltage for optimal performance with maximum usability
General Information
Specifications
ADI Part Number P9-P48D22M Brand Name Panduit Manufacturer PANDUIT CORP Manufacturer Part Number P48D22M Product Line SmartZone Product Name SmartZone G5 48-Outlets PDU Product Series G5 Product Type PDU
Output Voltage 208V PDU Type Monitored Phase Three Phase Receptacle Detail 24 x IEC 60320 C13/C15, 24 x IEC 60320 C13/C15/C19/C21 Receptacle Type IEC 60320 C13/C15, IEC 60320 C13/C15/C19/C21
Depth 2.4" Height 70" Rack Height 0U Width 2.2"
Input Current 30A Input Voltage 230V AC Plug/Connector Type NEMA L15-30P
Length 70" Mount Type Surface Mount
Limited Warranty 3-Year
Environmental Certification REACH, RoHS Environmentally Friendly Yes
