Product Overview
Federal Signal's Visalert® is a three dimensional, triangular warning light designed to be mated with Federal Signal's Model 350 Vibratone® horn and the Model 50GC SelecTone® speaker/amplifier. The Visalert can also be used as a stand alone device. Visalert is available in five lens colors: Amber, Blue, Clear, Green and Red.
Knockouts on the 50GC and 350 audible devices (sold separately) ensure easy installation. The units can be either independently or simultaneously wired with the audible device. The Visalert uses a linear strobe tube and all the circuitry is contained within the lens.
Visalert units are recommended for use in industrial applications and situations where effective visual warning is needed. The Visalert can be surface mounted on the Model 350 or Model 50GC speaker/amplifier.
Federal Signal's Visalert strobe light is an affordable, low-maintenance strobe light in a compact size that is perfect for control panel applications.
Main Features
- Available in 24V DC, 120V AC and 240V AC
- Five lens colors
- 4,000 hour strobe tube
- Surface mount on Federal Signal audible signaling devices or control panel
- Indoor/outdoor use
- Type 3R, IP44 enclosure
- UL Listed and CSA Certified
General Information
Specifications
-
ADI Part Number QF-VALS024C Brand Name Federal Signal Manufacturer Federal Signal Corporation Manufacturer Part Number VALS-024C Product Functions Alarm Product Line VALS Visalert Product Model VALS-024C Product Name VALS Visalert Strobe Light Product Type Security Strobe Light Weight (Approximate) (g) 45.359 Â
-
Alarm Type Visual Connectivity Technology Wired Â
-
Application/Usage Control Panel, Indoor, Industrial, Outdoor, Security Depth 1.6" Depth (mm) 40.64 Form Factor Surface Mount Height 4" Height (mm) 100.33 Lens Color Clear Product Color Clear Weight (Approximate) 1.60 oz Width 3.9" Width (mm) 100.076 Â
-
Input Voltage 24V DC Input Voltage (V DC) 24 Power Source DC Â
-
Mount Type Surface Mount Â
-
Indoor/Outdoor Indoor, Outdoor Â
