SDC EH421224A EH Series Electromagnetic Door Holder, Floor Mount Double, 12/24V AC/DC, Chrome Powder Coat
EH421224A|SZ-EH421224A
SDC EH421224A EH Series Electromagnetic Door Holder, Floor Mount Double, 12/24V AC/DC, Chrome Powder Coat
EH421224A|SZ-EH421224A
Key Features
- Door release and close upon power loss or fire life safety system activation
- Low power consumption
- Field selectable high holding force
Key Features
- Door release and close upon power loss or fire life safety system activation
- Low power consumption
- Field selectable high holding force
.jpg)
Key Features
- Door release and close upon power loss or fire life safety system activation
- Low power consumption
- Field selectable high holding force
Security Door Controls
SDC EH421224A EH Series Electromagnetic Door Holder, Floor Mount Double, 12/24V AC/DC, Chrome Powder Coat
EH421224A | SZ-EH421224A
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
SDC's EH series magnetic door holders are designed to hold doors open and release the door by remote switch or fire life safety command center activation. Primary application includes holding and releasing of fire rated doors that are required to provide a barrier for fire and smoke in an emergency or the convenience of door closure by remote control. Choice of 25, 30, 35 or 40lb holding force determined by units specified voltage. Reduced power supply requirements and energy costs due to low power consumption (15mA to 40mA). Field selectable high holding force comes standard, reducing stock or need to special order high holding force. Screw terminal block input connections for simple and neat wiring. Innovative installation eliminates the need for secondary alignment adjustments. Ball pivot assembly enables full plate contact and holding force. Optional adjustable rod compensate for extreme misalignment up to four". Slotted mounting holes enable adjustment of magnet centerline.
Main Features
- Door release and close upon power loss or fire life safety system activation
- Low power consumption
- Field selectable high holding force
- Dual AC/DC voltage configurations
- Screw terminal block input connections
- Self-aligning catch plate
- Adjustable magnet centerline
General Information
Name: SDC EH421224A EH Series Electromagnetic Door Holder, Floor Mount Double, 12/24V AC/DC, Chrome Powder Coat
Category: Security Door Controls, Access Control, Door Hardware, Electromagnetic Door Holders
UPC Code: 712905260860
Country of Origin: United States. Country of origin is subject to change.
Specifications
-
ADI Part Number SZ-EH421224A Brand Name Security Door Controls Manufacturer Part Number EH421224A Product Series EH
