Image of TC-3000CRMXL
Shop all Eaton Tripp Lite

Eaton Tripp Lite SMART3000CRMXL SmartPro 120 3kV 2.88kW, Line-Interactive Sine Wave UPS, 4U Short Depth, Extended Run, Network Card Options, USB, DB9

SMART3000CRMXL|TC-3000CRMXL
Shop all Eaton Tripp Lite

Eaton Tripp Lite SMART3000CRMXL SmartPro 120 3kV 2.88kW, Line-Interactive Sine Wave UPS, 4U Short Depth, Extended Run, Network Card Options, USB, DB9

SMART3000CRMXL|TC-3000CRMXL
Key Features
What's Included
  • Compact rack-mount UPS with line interactive voltage regulation
  • Ideal for network and telecom wiring closets
  • Expandable runtime with optional external battery packs
Key Features
What's Included
  • Compact rack-mount UPS with line interactive voltage regulation
  • Ideal for network and telecom wiring closets
  • Expandable runtime with optional external battery packs

Sign In for Dealer Pricing

Become an ADI Customer
Key Features
What's Included
  • Compact rack-mount UPS with line interactive voltage regulation
  • Ideal for network and telecom wiring closets
  • Expandable runtime with optional external battery packs
Eaton Tripp Lite

Eaton Tripp Lite SMART3000CRMXL SmartPro 120 3kV 2.88kW, Line-Interactive Sine Wave UPS, 4U Short Depth, Extended Run, Network Card Options, USB, DB9

SMART3000CRMXL | TC-3000CRMXL

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

This SmartPro compact rack-mount Uninterruptible Power Supply (UPS) offers line-interactive voltage regulation, network-grade surge suppression and long-lasting battery support for critical network hardware during blackouts and extended power failures. Special reduced-depth housing, larger internal batteries, higher rated wattage and included 2-post rack-mount installation hardware make these systems ideal for network and telecom wiring closets and other limited-space installations. Runtime is expandable with optional BP48V24-2U (limit 1), BP48V48RT4U (multi-pack compatible) and BP48V27-2US (multi-pack compatible) external battery packs. SMART3000CRMXL 4U rack-mount 3000VA UPS offers battery-derived sine wave AC output during power failures and extreme voltage variations. Supports 3000VA/2880W when powered via included L5-30P input plug. Supports up to 3600VA/3600W when hardwired to a 120V 30A input source. Line-interactive Automatic Voltage Regulation (AVR) provides two levels of voltage boost during brownouts and one level of voltage cut during overvoltage conditions to maintain regulated 120V nominal output over an input range of 83-145V. Includes NEMA L5-30P input plug (or hardwire input), L5-30R and 5-15/20R output receptacles. Network management interfaces support communications via USB, RS-232 and installed Network Management Card option. HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows and macOS. Supports detailed monitoring of equipment load levels, self-test data and utility power conditions via all three network interfaces at once. PowerAlert UPS monitoring software is available via free download. Emergency Power Off (EPO) interface. Integrated three-bank programmable PDU switching supports load shedding and remote-reboot of up to three individual connected devices. Three-stage metered current monitoring and battery charge status LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 2-post rack-mount accessories included; 2-9USTAND tower stands and 4POSTRAILKIT 4-post rack-mount kit available. Field-replaceable, hot-swappable internal batteries and external battery packs. Attractive all-black color scheme.

Main Features

  • Compact rack-mount UPS with line interactive voltage regulation
  • Ideal for network and telecom wiring closets
  • Expandable runtime with optional external battery packs
  • Intelligent battery management extends battery life
  • 3000VA / 2880W UPS with sine wave AC output
  • Supports up to 3600W when hardwired
  • Automatic Voltage Regulation for stable 120V output
  • Multiple network management interfaces for communication
  • 97% Efficiency in line Power mode reduces costs
  • Integrated PDU switching for load shedding and remote reboot

General Information

Name: Eaton Tripp Lite SMART3000CRMXL SmartPro 120 3kV 2.88kW, Line-Interactive Sine Wave UPS, 4U Short Depth, Extended Run, Network Card Options, USB, DB9
Category: Batteries & Power Supplies, Power Management, UPS
UPC Code: 037332142375
Country of Origin: China. Country of origin is subject to change.

Specifications

Product Documents and Resources

Product Data Sheet
Manufacturer Brochure
