Eaton Tripp Lite NM12-6A2-10M-BL 23/4 Shielded Solid Copper Ethernet Cable, M12 Male RJ45 Male, CMR, 32.8' (10m), Blue
NM12-6A2-10M-BL | TC-NM126A210
Please sign in to view pricing and availability and to add to cart.
Product Overview
Cat6a M12 Cable Recommended for Industrial and Other Harsh Environments
This M12 X-Code cable connects 10 GbE networks in wet/humid environments, places subject to vibration and other areas where protection from harsh elements is essential, such as factories, warehouses, recycling plants, airports, railways and machine shops. The circular M12 connector with 12-millimeter locking thread is especially designed for washdown and corrosive applications, including agriculture, alternative energy, communications, factory automation, measurement and control, robotics, transportation and food/beverage facilities.
IP68 Rating Denotes Resistance to Dust and Water
The IP68 rating means the M12 connector end is not only 100% protected against dust, but also able to endure immersion in 1.5 meters of water for up to 60 minutes with no damage or decline in performance.
Supports Power over Ethernet to Save You Money and Give You More Installation Choices
Because this Cat6a cable supports high-power 60W PoE, it can supply the power to operate compatible data, voice, security and audio/video PoE devices, such as surveillance cameras, VoIP telephones and access control devices. This saves you the expense and effort of purchasing, connecting and installing individual power supplies for each device, as well as installing separate power and data cables. It also helps you install PoE devices in areas far away from AC outlets, such as poles or ceilings.
CMR-LP Certified for Cable Installations with Increased Power Levels
UL's Limited Power (LP) certification indicates the NM12-6A2-10M-BL has been evaluated to handle the marked current under installation scenarios without exceeding the temperature rating of the cable. This CMR-LP-certified cable provides a simple way to prepare installations for increased power levels without having to worry about susceptible issues caused by excessive heat.
Colored Blue to Avoid Misidentification That Can Cause Costly Downtime
This Cat6a F/UTP copper cable features a blue PVC jacket that allows easy, fast identification in field devices, controllers and switches and helps prevent the cable from becoming inadvertently disconnected.
Main Features
- 10G Ethernet connectivity for industrial environments
- IP68-Rated for dust and water resistance
- Supports 60W Power over Ethernet (PoE)
- M12 X-Code Connector for harsh conditions
- CMR-LP Certified for increased Power levels
- Blue PVC jacket for easy identification
- Ideal for factories, warehouses, and more
- Prevents costly downtime with secure connections
General Information
Specifications
-
ADI Part Number TC-NM126A210 Brand Name Eaton Tripp Lite Manufacturer Eaton Manufacturer Part Number NM126A210MBL Product Model NM12-6A2-10M-BL Product Name NM12-6A2-10M-BL Cat.6a Network Cable Product Type Network Cable
-
American Wire Gauge 23AWG Cable Type Category 6a Device Supported Access Control Device, Controller, Network Device, Security Device, Surveillance Camera, Switch, VoIP Device Jacket Type CMR-LP Shielding Yes Solid or Stranded Solid
-
TAA Compliant Yes
-
Data Transfer Rate 10 Gbit/s
-
Cable Length 32.81' Color Blue
-
Limited Warranty Lifetime
-
Country of Origin TW Environmentally Friendly Yes Features Lockable, PoE, PoE++ Package Contents - NM12-6A2-10M-BL M12 X-Code Cat6a 10G Ethernet Cable, M12 M/RJ45 M, Blue, 10 m (32.8 ft.)
