Eaton Tripp Lite P130-000-AUDIO 4K HDMI Audio Embedder, Extractor with TOSLINK and 3.5mm stereo output, 5.1", HDCP, 4K 30Hz

P130-000-AUDIO|TC-P130000AU
Shop all Eaton Tripp Lite

Eaton Tripp Lite P130-000-AUDIO 4K HDMI Audio Embedder, Extractor with TOSLINK and 3.5mm stereo output, 5.1", HDCP, 4K 30Hz

P130-000-AUDIO|TC-P130000AU
Key Features
  • Extracts audio from HDMI for separate audio systems
  • Compatible with speakers lacking HDMI input
  • Offers 3.5mm, TOSLINK, and RCA outputs
Key Features
  • Extracts audio from HDMI for separate audio systems
  • Compatible with speakers lacking HDMI input
  • Offers 3.5mm, TOSLINK, and RCA outputs

Sign In for Dealer Pricing

Become an ADI Customer
Key Features
  • Extracts audio from HDMI for separate audio systems
  • Compatible with speakers lacking HDMI input
  • Offers 3.5mm, TOSLINK, and RCA outputs
Eaton Tripp Lite

Eaton Tripp Lite P130-000-AUDIO 4K HDMI Audio Embedder, Extractor with TOSLINK and 3.5mm stereo output, 5.1", HDCP, 4K 30Hz

P130-000-AUDIO | TC-P130000AU

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The P130-000-AUDIO UHD 4Kx2K HDMI Audio De-Embedder/Extractor is an ideal solution for connecting an HDMI source, such as a Blu-ray player or video game system, to audio speakers that don't have an HDMI input port. It separates the audio track from the HDMI signal and sends it directly to an alternate HDMI audio system. It features 3.5mm stereo, TOSLINK digital optical and RCA digital audio outputs to match most non-HDMI receivers and audio systems. The P130-000-AUDIO supports both two-channel stereo and multi-channel audio up to 5.1 surround sound. It also supports both uncompressed audio, such as LPCM, and compressed audio formats, including DTS and Dolby Digital. An LED indicates when the unit is receiving power, transmitting an audio/video signal or transmitting 5.1-channel surround sound. On the video side, the P130-000-AUDIO transmits Ultra High Definition (UHD) video resolutions up to 3840x2160 (4Kx2K) at 30 Hz. It supports 24-bit True Color (8 bits per channel) at 4Kx2K, 36-bit Deep Color (12 bits per channel) at 1080p, and optional 3D formats up to 50/60 Hz. Product is also HDCP compatible.

Main Features

  • Extracts audio from HDMI for separate audio systems
  • Compatible with speakers lacking HDMI input
  • Offers 3.5mm, TOSLINK, and RCA outputs
  • LED Power and signal transmission indicator
  • Includes international Plug adapters
  • Supports 2-Channel and 5.1 surround sound
  • Handles uncompressed and compressed audio
  • Transmits 4K UHD Video at 30Hz
  • Supports 24-bit True Color and 36-bit Deep Color
  • Compatible with optional 3D formats

General Information

Name: Eaton Tripp Lite P130-000-AUDIO 4K HDMI Audio Embedder, Extractor with TOSLINK and 3.5mm stereo output, 5.1", HDCP, 4K 30Hz
Category: Residential AV, Pro AV, Residential Video Signal Distribution, Commercial Video Signal Distribution, HDMI Splitters, Pro HDMI Splitters
UPC Code: 037332193193
Country of Origin: China. Country of origin is subject to change.

Specifications

Product Documents and Resources

Product Data Sheet
User Manual
Manufacturer Brochure
Certification / Declaration
