Product Overview
The 120V, 1500VA / 900W Interactive SmartPro SMART1500LCD Uninterruptible Backup System with LCD provides AC power backup and protection against blackouts, brownouts, surges, and line noise that can damage electronics or destroy data. Ideal for backing up your desktop computer or AV components, these interactive UPS switch to battery backup mode in milliseconds to keep your equipment connected long enough to save files and safely shut down without data loss.
Eight NEMA 5-15R outlets protect against surges, as well as provide up to 11.8 minutes of UPS battery backup at half load (450W) and 4.4 minutes of backup at full load (900W). Automatic Voltage Regulation (AVR) corrects severe undervoltages of up to 75V and overvoltages of up to 147V without using battery power. EMI / RFI noise filtering improves the performance of your equipment and prevents damage. A 480 joule surge suppression specification protects your equipment against harmful surges.
NEMA 5-15P plug with 6 ft [1.83 m] cord connects to any NEMA 5-15R outlet. The large, rotatable LCD screen with dimmer displays real-time input voltage, overload, AVR and battery statuses at a glance. The alarm sounds to indicate power loss or low battery. With Free PowerAlert Software (available via free download) the SMART1500LCD enables safe system shutdown and unattended file saving in the event of a prolonged power failure.
Package included
- SmartPro SMART1500LCD Interactive 120V 1500VA / 900W UPS with LCD
- USB Cable
- Serial DB9 Cable
- Telephone cable
- Installation accessories
- Owner's manual
General Information
Name : Tripp Lite SMART1500LCD SmartPro LCD 120V 1500VA 900W Line-Interactive UPS, AVR, 2U Rack/tower, LCD, USB, DB9 Serial, 8 Outlets , Tripp Lite by Eaton
Category : UPS
UPC Code : 037332126146
Country of Origin : China. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : TC-SMT1500LC
Brand Name : Tripp Lite
Manufacturer : Tripp Lite by Eaton
Manufacturer Part Number : SMART1500LCD
Product Line : SmartPro
Product Name : SmartPro 1500 VA Rackmount/Tower Digital UPS
Product Type : Line-interactive UPS
Weight (Approximate) (g) : 13154.179
Technical Information
Backup/Run Time (Full Load) : 3.50 Minute
Backup/Run Time (Full Load) (Second) : 210
Backup/Run Time (Half Load) : 13 Minute
Backup/Run Time (Half Load) (Second) : 780
Dataline Protection : RJ-45
Output Voltage : 120V AC
Output Voltage (V AC) : 120
Receptacle Detail : 8 x NEMA 5-15R
Receptacle Type : NEMA 5-15R
Transfer Time : 4 ms
Transfer Time (Second) : 0.004
Battery Information
Typical Battery Recharge Time : 8 Hours
Typical Battery Recharge Time (Second) : 28800
Category Specific Attributes
Output Voltage (V) : 120
Surge Energy Rating (J) : 480
Environmental Conditions
Maximum Operating Temperature : 122°F (50°C)
Maximum Operating Temperature (°F) : 122
Interfaces/Ports
Serial Port : Yes
Physical Characteristics
Color : Black
Depth : 10.5"
Depth (mm) : 266.7
Form Factor : Rack, Tower
Height : 17.3"
Height (mm) : 438.15
Rack Height : 2U
Weight (Approximate) : 29 lb
Width : 3.5"
Width (mm) : 88.9
Power Description
Input Voltage : 110V AC
Input Voltage (V AC) : 110
Plug/Connector Type : NEMA 5-15P
Surge Energy Rating : 480 J
Waveform Type : Pulse-width Modulated Sine Wave
Product Information
Load Capacity (VA) (W) : 1500VA, 900W
Load Capacity (W) : 1500.000
Warranty
Limited Warranty : 2-Year
Miscellaneous
Country of Origin : China
Package Contents : <ul><li>SmartPro 1500 VA Rackmount/Tower Digital UPS</li><li>USB Cable</li><li>Serial Cable</li><li>Mounting Hardware</li><li>Manual with Warranty Information</li></ul>
