Eaton Tripp Lite U330-10M Active USB 3.0 SuperSpeed (AM/F) Extension Repeater Cable, 33' (10m)
U330-10M|TC-U33010M
Eaton Tripp Lite U330-10M Active USB 3.0 SuperSpeed (AM/F) Extension Repeater Cable, 33' (10m)
U330-10M|TC-U33010M
Key Features
What's Included
- USB 3.0 SuperSpeed for fast data transfer
- Extends USB signal up to 32.8' (10 m)
- Connect two cables for 65.61' (20 m) Extension
Key Features
What's Included
- USB 3.0 SuperSpeed for fast data transfer
- Extends USB signal up to 32.8' (10 m)
- Connect two cables for 65.61' (20 m) Extension
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
What's Included
- USB 3.0 SuperSpeed for fast data transfer
- Extends USB signal up to 32.8' (10 m)
- Connect two cables for 65.61' (20 m) Extension
Eaton Tripp Lite
Eaton Tripp Lite U330-10M Active USB 3.0 SuperSpeed (AM/F) Extension Repeater Cable, 33' (10m)
U330-10M | TC-U33010M
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
This USB 3.0 active extension cable is a bus-powered cable that can be used to increase the length of a device cable without the worry of signal loss and potential performance problems. Increase the extension distance to 65.6 feet (20 meters) by connecting two U330-10M cables together. USB limits a cable's length to 16 feet (4.9 meters). Any length above 16 feet requires the use of an active cable such as this one. This cable has a signal booster built in. The cable must be plugged directly into a USB port (either on the PC or a hub). Use a standard six' (1.8m), 10' (3.1m), or 15' (4.6m) USB 3.0 A/B cable to reach the desired distance. The U330-10M provides up to 120mA of power to the connected device. If your device requires more than 120mA of power, an external power supply (not included) will be required. The U330-10M accepts a 5V 2A power supply with a 3.5x1.35mm DC jack. The output plug on the power supply should have a positive tip and a negative sleeve.
Main Features
- USB 3.0 SuperSpeed for fast data transfer
- Extends USB signal up to 32.8' (10 m)
- Connect two cables for 65.61' (20 m) Extension
- Compatible with standard USB 3.0 cables
- Provides up to 120mA Power to devices
- Supports external Power supply for higher Power needs
- Backward compatible with older USB versions
General Information
Name: Eaton Tripp Lite U330-10M Active USB 3.0 SuperSpeed (AM/F) Extension Repeater Cable, 33' (10m)
Category: Pro AV, Commercial Connector Cables, Pro USB Cables
UPC Code: 037332182722
Country of Origin: China. Country of origin is subject to change.
Specifications
-
ADI Part Number TC-U33010M Brand Name Eaton Tripp Lite Manufacturer Eaton Manufacturer Part Number U330-10M Packaged Quantity 1 Product Model U330-10M Product Name USB 3.0 SuperSpeed Active Extension Repeater Cable (A M/F) 10M (33-ft.) Product Type Data Transfer Cable
-
Cable Type USB Connector on First End USB Type A Male Connector on Second End USB Type A Female
-
Connector Type USB 3.0 A (MALE)
-
Cable Length 32.8' Color Black
-
Limited Warranty 3-Year
-
Country of Origin CN Environmental Certification RoHS Environmentally Friendly Yes Features Active, Repeater, Signal Booster Package Contents - 32.8-ft. (10 m) USB3.0 Super Speed A/A Active Extension Cable (USB-A M/F)
