Product Overview
TRENDnet's 5-Port Gigabit EdgeSmart Switch, model TEG-S50ES, is a cost-effective switch solution for high-speed gigabit applications. This 5-port smart switch features the most commonly used managed switch features, reducing unnecessary switch complexity. The web-based management interface offers features for traffic control, RSTP, VLAN, QoS, access control, static link aggregation, and monitoring. TRENDnet's TEG-S50ES allows for simple network integration into your SMB network.
Main Features
- Ethernet port configuration; 5 x Gigabit ports. 10 Gbps Switching capacity
- EdgeSmart network management; This 5-Port Gigabit Switch provides an easy-to-use web-based management interface for reduced switch configuration complexity and offers a combination of more commonly used SMB management features for easy deployment. The web-based management interface offers features for loopback detection, RSTP, static link aggregation, VLAN, IGMP Snooping, and QoS
- Integration flexibility; Managed features for the network switch include loopback detection, RSTP, static link aggregation, VLAN, IGMP Snooping, and QoS for flexible network integration
- The 5-port smart switch includes SNMP, SNMP Trap, and Port Mirroring for support administrator monitoring solutions
- With a fanless compact and lightweight metal housing design, this 5-port smart switch is well-suited for desktop and wall mount installations
- Qualty of service (QoS); Port-based QoS, 802.1p Class of Service (CoS), Bandwidth Control/Rate Limiting per port (Min. Limit: 8 Kbps), and Queue Scheduling: Strict Priority (SP), Weighted Fair Queueing (WFQ)
General Information
Name: TRENDnet TEG-S50ES 5-Port Gigabit EdgeSmart Switch, 10 Gbps
Category: TRENDnet, Data Comm & Networking, Hubs, Routers & Switches, Network Switches
UPC Code: 710931140491
Country of Origin: Taiwan. Country of origin is subject to change.
Specifications
ADI Part Number TQ-TEGS50ES Brand Name TRENDnet Country of Origin TW Manufacturer TRENDnet Manufacturer Part Number TEG-S50ES Product Line EdgeSmart Product Model TEG-S50ES Product Name 5-Port Gigabit EdgeSmart Switch Product Series TEG Product Type Ethernet Switch
Maximum Data Transfer Rate 1.0Gbps Media Type Supported Twisted Pair Network Switch Type Managed Power Consumption 3.4200W
NDAA Compliant Yes TAA Compliant Yes
Shared SFP Slot No
Modular No Total Number of Network Ports 5 Uplink Port No
Manageable Yes
Network Technology 1000Base-T, 100Base-T, 10Base-T
Ethernet Technology Gigabit Ethernet Layer Supported 2 Networking Standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Depth 6.00" Height 2.00" Material Metal Weight 6.16oz Width 3.00"
Frequency 60.00Hz Input Voltage 100-240V AC PoE (RJ-45) Port No Power over Ethernet (PoE) No Power Source AC Power
Length 4.00" Mount Type Desktop Mount
Limited Warranty Lifetime
Environmentally Friendly Yes Package Contents Power adapter (5V DC, 1A), Quick Installation Guide, TEG-S50ES
