Superior Essex 52-200-48 CAT5e+ 24/4 Solid Annealed Plenum Copper Cable, Theroplastic / FRPVC, 1000' Reel-In-A-Box, White
52-200-48
|UY-5220048
Shop all Superior Essex
Superior Essex 52-200-48 CAT5e+ 24/4 Solid Annealed Plenum Copper Cable, Theroplastic / FRPVC, 1000' Reel-In-A-Box, White
52-200-48 | UY-5220048
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Cobra Category 5e+ cable is the performance leader in its class. Cobra cable is ideal for installations that require true "future proofing" in channel performance. By design, Cobra cables are manufactured to the highest quality standards, design requirements and materials to ensure that every box provides significant margin over ANSI/TIA-568-C.2 specifications for NEXT, Power Sum NEXT and Insertion Loss.
Main Features
- Guaranteed NEXT of 3 dB greater than ANSI/TIA-568-C.2 specification across frequency range
- Guaranteed ACR of 19.5 dB at 100 MHz
- Exceptional PSNEXT, PSELFEXT and PSACR over CAT5e
- "WideMouth" POP Box design
- CableID Alpha numeric code printed every 2'
- QuickCount marking system in feet and meters
- ColorTip circuit identification system
- Color coded box labels
General Information
Name: Superior Essex 52-200-48 CAT5e+ 24/4 Solid Annealed Plenum Copper Cable, Theroplastic / FRPVC, 1000' Reel-In-A-Box, White
Category: Superior Essex, Wire & Cable, Network Cables, Category 5e Network Cables
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number UY-5220048 Brand Name Superior Essex Manufacturer Part Number 52-200-48
American Wire Gauge 24AWG Cable Rating Plenum Cable Type Category 5e Number of Pairs 4
Color White
Environmental Certification RoHS, UL Environmentally Friendly Yes
