Dahua IPC-L46N-USA Wi-Fi Series 4MP LincX2PRO Floodlight Camera with Active Alarm and Siren, 2.8mm Fixed Lens, White
IPC-L46N-USA|VD-IPCL46NUS
Dahua IPC-L46N-USA Wi-Fi Series 4MP LincX2PRO Floodlight Camera with Active Alarm and Siren, 2.8mm Fixed Lens, White
IPC-L46N-USA|VD-IPCL46NUS
Key Features
- 1/3-" 4MP Progressive-scan CMOS Sensor
- 4MP (2560 x 1440) at 30 fps, 2.8 mm Fixed Lens
- 2.4 or 5 GHz WiFi Options, IEEE802.11a/b/g/n/ac
Key Features
- 1/3-" 4MP Progressive-scan CMOS Sensor
- 4MP (2560 x 1440) at 30 fps, 2.8 mm Fixed Lens
- 2.4 or 5 GHz WiFi Options, IEEE802.11a/b/g/n/ac
.jpg)
Key Features
- 1/3-" 4MP Progressive-scan CMOS Sensor
- 4MP (2560 x 1440) at 30 fps, 2.8 mm Fixed Lens
- 2.4 or 5 GHz WiFi Options, IEEE802.11a/b/g/n/ac
Dahua
Dahua IPC-L46N-USA Wi-Fi Series 4MP LincX2PRO Floodlight Camera with Active Alarm and Siren, 2.8mm Fixed Lens, White
IPC-L46N-USA | VD-IPCL46NUS
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
System Overview
The Dahua LincX2PRO Series includes the IPC-L46N, a floodlight camera with a 4MP CMOS sensor, 2.8 mm fixed lens, and two powerful 2400 Lumen floodlights to provide illuminate the property and deter any prospective attackers. The camera is equipped with Dahua's Analytics+ which focuses on human and vehicle targets to reduce false warnings. You can converse with visitors or intruders on your property using the camera's two-way audio thorugh the DMSS mobile app.
Functions
Smart H.264+ and Smart H.265+
Delivering high quality video without straining the network, Smart H.264+ is the optimized implementation of H.264. The Smart H.264+ encoding platform includes a scene adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction, providing a savings of up to 70% of bandwidth and storage when compared with standard H.264.
Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces bit rate and storage requirements by up to 70% when compared to standard H.265 video compression.
Smart Dual Illumination
The camera offers both IR and white-light illuminators and intelligently employs each depending on the situation. Typically, the camera enters the IR mode as ambient light decreases. When the camera detects an object entering the monitoring area, it activates the white-light illuminator to capture full-color details. Once the object leaves the area, the camera switches back to IR illumination.
Day/Night
A day/night mechanical IR cut filter makes this camera ideal for applications with fluctuating lighting conditions, delivering color images during the day and automatically switching to monochrome as the scene darkens.
Cybersecurity
Dahua network cameras are equipped with a series of key cybersecurity technologies including: security authentication and authorization, access control, trusted protection, encrypted transmission, and encrypted storage. These technologies improve the camera's ability to prevent malicious access and to protect data.
Functions
The Dahua LincX2PRO Series includes the IPC-L46N, a floodlight camera with a 4MP CMOS sensor, 2.8 mm fixed lens, and two powerful 2400 Lumen floodlights to provide illuminate the property and deter any prospective attackers. The camera is equipped with Dahua's Analytics+ which focuses on human and vehicle targets to reduce false warnings. You can converse with visitors or intruders on your property using the camera's two-way audio thorugh the DMSS mobile app.
Functions
Smart H.264+ and Smart H.265+
Delivering high quality video without straining the network, Smart H.264+ is the optimized implementation of H.264. The Smart H.264+ encoding platform includes a scene adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction, providing a savings of up to 70% of bandwidth and storage when compared with standard H.264.
Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces bit rate and storage requirements by up to 70% when compared to standard H.265 video compression.
Smart Dual Illumination
The camera offers both IR and white-light illuminators and intelligently employs each depending on the situation. Typically, the camera enters the IR mode as ambient light decreases. When the camera detects an object entering the monitoring area, it activates the white-light illuminator to capture full-color details. Once the object leaves the area, the camera switches back to IR illumination.
Day/Night
A day/night mechanical IR cut filter makes this camera ideal for applications with fluctuating lighting conditions, delivering color images during the day and automatically switching to monochrome as the scene darkens.
Cybersecurity
Dahua network cameras are equipped with a series of key cybersecurity technologies including: security authentication and authorization, access control, trusted protection, encrypted transmission, and encrypted storage. These technologies improve the camera's ability to prevent malicious access and to protect data.
Functions
Main Features
- 1/3-" 4MP Progressive-scan CMOS Sensor
- 4MP (2560 x 1440) at 30 fps, 2.8 mm Fixed Lens
- 2.4 or 5 GHz WiFi Options, IEEE802.11a/b/g/n/ac
- Smart H.265+ and Smart H.264+ Dual Codecs
- Maximum Resolution of 4MP at 30 fps
- Active Alarm with Integrated 110 dB Siren and Floodlight
- Built-in Microphone and Speaker
- IP65 Ingress Protection
General Information
Name: Dahua IPC-L46N-USA Wi-Fi Series 4MP LincX2PRO Floodlight Camera with Active Alarm and Siren, 2.8mm Fixed Lens, White
Category: Dahua, Smart Home, Smart Security Cameras
UPC Code: 810053975916
Country of Origin: China. Country of origin is subject to change.
Specifications
-
ADI Part Number VD-IPCL46NUS Brand Name Dahua Manufacturer Zhejiang Dahua Technology Co., Ltd. Manufacturer Part Number IPC-L46N-USA Product Line LincX2Pro Product Model IPC-L46N-USA Product Name 4MP LincX2PRO WiFi Floodlight Camera Product Series WiFi Product Type Network Camera Weight 3.09lb
-
Connectivity Technology Wireless Effective Camera Resolution 4MP Field of View 115° Diagonal, 98° Horizontal, 55° Vertical Lens Type Fixed Maximum Aperture f/1.6 Maximum Frame Rate 30 fps Minimum Focal Length 2.8mm Night Vision Yes Night Vision Type Color, Infrared Number of IR LEDs 1 Video Formats H.264, H.265, MJPEG
-
Image Sensor Type CMOS Night Vision Distance 32.81 ft
-
Ingress Protection Rating IP65
-
Maximum Video Resolution 2560 x 1440
-
Maximum Operating Temperature 122°F (50°C) Minimum Operating Temperature -4°F (-20°C) Operating Humidity 95%
-
Longest Shutter Speed 1/3 Second Shortest Shutter Speed 1/100000 Second
-
Lens Included Yes Maximum Focal Length 2.80 mm
-
Remote Management Yes
-
ADI Part Number Replaces VD-IPCL26N Model Number Replaces IPC-L26N
-
Color White Durability Dustproof, Waterproof Form Factor Floodlight Height 7.7" Width 8.6"
-
Input Voltage 100V AC, 240V AC
-
Length 10.7"
-
Storage Type Memory Card
-
Maximum Resolution 1280 x 720
-
Country of Origin CN Features 3D Noise Reduction, Automatic White Balance, Back Light Compensation (BLC), Built-in Microphone, Built-in Siren, Built-in Speaker, Day/Night, Digital Wide Dynamic Range (D-WDR), Highlight Compensation (HLC), Motion Detection, Privacy Masking, Region of Interest, SD Card Local Storage
